MPPT48Z-E Series Mppt Solar Charge Controller
US$ 48.00 - 48.00
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
KEMAPOWER
Model Number:
MPPT48Z-E
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HT30DU Series10A 20A 30A PWM Solar Charge Controller With LCD DisplayUS$ 10.5 - 21MOQ: 500 Pieces -
HT30U Series10A 20A 30A PWM Solar Charge ControllerUS$ 6.72 - 11.52MOQ: 50 Pieces
-
HT60D Series 40A 50A 60A PWM Solar Charge ControllerUS$ 26.8 - 46MOQ: 30 Pieces
-
MPPT1224 20-50Amp Solar Regulator ControllerUS$ 10 - 50MOQ: 1 Piece
-
PWM Solar Charge Controller HN(R) SeriesUS$ 10 - 20MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
KEMAPOWER
Model Number
MPPT48Z-E
Rated Voltage
Other, 12/24/48V
Maximum Current
15/20/25/30/40A
Key Features
1.LCD display MPPT(Maximum Power Point Tracking) solar charge controller
2.12V/24V/48VDC automatic recognition, Max PV input 100VDC
3.Three Stages charging, fast charge/Constant charge/Floating charging
4.Vented, Sealed, Gel, NiCd battery or customer other battery selectable.
5.User-Defined charge voltage by software
6.LCD+LED Display the input and output parameter of PV and battery
7.with Temperature Compensation
8.RS232 Communication For Operating and testing
9.Extensible LAN remote control optional
Technical Specifications
| Item | Model | MPPT48Z-15E | MPPT48Z-20E | MPPT48Z-25E | MPPT48Z-30E | MPPT48Z-40E |
| Output | System DC Voltage | DC12V/24V/48V Automatic recognition | ||||
| Output VDC Precision | ≤±1.5% | |||||
| Rated Output Current | 15A | 20A | 25A | 30A | 40A | |
| Current-limiting Protection | 20A | 25A | 30A | 35A | 45A | |
| Over Charge Protection | 14.6V For 12VDC System, *2 for 24VDC, *4 For 48VDC | |||||
| Selectable battery | Sealed lead acid, vented, Gel, NiCd, or defined by user | |||||
| Temperature Compensation | 14.2V-(The highest temperature-25℃)*0.3 | |||||
| Load output | Voltage | Follow the battery bank voltage | ||||
| Current | Max 30AMP, | |||||
| Input | MPPT Range | DC14V~DC100V For 12VDC system, DC30~DC100V For 24VDC, DC60~DC100V For 48VDC | ||||
| 12VDC Max PV input (W) | 213 | 284 | 355 | 426 | 568 | |
| 24VDC Max PV input (W) | 426 | 568 | 710 | 852 | 1136 | |
| 48VDC Max PV input (W) | 852 | 1136 | 1420 | 1704 | 2272 | |
| Low Voltage Input Protection | DC14V for 12V system,DC30V for 24V ,DC60V for 48V | |||||
| Low Voltage Input Recovery | DC18V for 12V system,DC34V for 24V ,DC65V for 48V | |||||
| Overvoltage Protection | 110VDC | |||||
| Overvoltage Recovery | 100VDC | |||||
| Display | LED digital tube display | Battery Voltage,Charge current | ||||
| LED light display | Charging indicator light, LOAD indicator light | |||||
| Communication | RS232 Communication by PC, | |||||
| Protection | Input Low Voltage Over voltage and over capacity Protection, output low Voltage over voltage protection, Over Temperature protection; Reverse polarity and short circuit by Fuse | |||||
| IP grade | IP25 | |||||
| Operating Temperature | ||||||
| Physical | Product size | D205*W168*H60 mm | ||||
| Package size | D265*W196*H110mm | |||||
| G.N/N.G(kg) | 2/1.8KG | |||||
