2012 hot selling low fuel consumption coal gasification generator
1:Saving energy
2:Without pollution
3:ISO9001-2008,SGS
4:temperature can be 1500 degree
Coal Gasification Generator Brief Introduction:
Coal Gasification Generator which is designed and manufactured by Guoxin factory use air and water vapor as the gasification agent, coal gasifier can use coal or coke as raw material, is an advanced equipment.
This equipment use coal accord with a country only "atmospheric fixed bed gas furnace with coal technology conditions of GB9143-2001 regulations, gas production from 500-5000 m3 / h, we have variety of specifications for customers to choose.
Coal gasification generator mainly used in machine, metallurgy, non-ferrous metal, chinaware, glass, chemical industries.
Coal Gasification Generator Working Principle:
Solid coal can be gasified into inflammable gases through vapor media. This coal gas is then dedust and conveyed through a conveying pipe to burn at a nozzle. The heat produced is used to heat the thermal furnace.
Coal Gasification Generator Advantages:
[1] High heat efficiency, full burning of the coal which can reduce the energy consumption. Compare with
direct heating by burning the coal it can save 20%-40% fuel.
[2] Using of the coal gasification generator can make the supporting kiln temperature achieves 1500
degree.
[3] The coal gasification generator conforms to the industry kiln gas to discharge the GB9079.88 waste
residue the platoon Uses the wet dregs, does not have the dirt, so it has certain social efficiency.
[4] Using of the gasification can improve the labor environment obviously, reduce the labour intensity.
Our coal gasification generator in the foreign market is very promising.
Our team continuously update our technology and produce
suitable, top-class coal gasification generator with competitive price for our
customers.
Clients from all over the world come to China to visit our factory.
Coal Gasification Generator Technical Parameter:
Name |
Coal gasifier |
||||||||||
Internal Diameter(m) |
0.6 |
0. 6 |
1 |
1.2 |
1.4 |
1.6 |
1.8 |
||||
Sectional Area(m³) |
0.28 |
0.5 |
0.78 |
1.13 |
1.53 |
2 |
2.54 |
||||
Fuel Consumption(kg/h) |
60-90 |
100-130 |
150-210 |
220-265 |
250-300 |
350-450 |
480-580 |
||||
Gas Production(Nm/h) |
180/270 |
300/270 |
450/630 |
600/295 |
750/900 |
1050/1350 |
1440/1740 |
||||
Cleaner Way |
Hand Cleaner |
||||||||||
Internal Diameter(m) |
2 |
2.2 |
2.4 |
2.6 |
2.8 |
3 |
3.2 |
||||
Sectional Area(m³) |
3.14 |
3.29 |
4.52 |
5.3 |
6.15 |
7.06 |
8.03 |
||||
Fuel Consumption(kg/h) |
600-850 |
900-1000 |
1000-1200 |
1200-1500 |
1600-1800 |
2400-2600 |
2400-2600 |
||||
Gas Production(Nm/h) |
1800/2550 |
2700/3000 |
3000/3600 |
3600/4500 |
4800/5400 |
6000/7200 |
7200/7800 |
||||
Cleaner Way |
Machine Cleaner |
Worm Gear |
|||||||||
Fuel Standard |
anthracite,bitumite, lignite,coke |
||||||||||
Gasification Agent |
Gas + Water |
||||||||||
Gas Caloricity(Kj/nm) |
5025-5650(1200-1450 Kcal) |
||||||||||
Gas Outlet Temperature( |
200-450 Can be adjusted according to the coal quality situation) |
||||||||||
Gas Outlet Pressure(Pa) |
900 |
||||||||||
Saturation Temperature() |
45-70 |
||||||||||
Quality Of Coal |
<70 |
||||||||||
Working Pressure |
Heat should be over 6000 Kcal,Per kilogram of coal can produce three cubic coal gas |
||||||||||
If you have any other question
Please contact me at any time
We have confidence to provide you top-class coal gasification
generator
