Specifications
Coal Gas Gasifier1.Low Fuel Consumption
2.Working Stable
3.Large Gas Output
4.High Caloric Value Coal Gas
Coal Gas Gasifier Brief Description
Coal gas gasifier which designed and manufactured by GUOXIN factory use air and steam as the gasifying agent, the applicable coal can be blind coal, bituminous coal and so on.
CG coal gas gasifier is the advanced equipment. It's widely used in machinery, metallurgical, chemical, glass, building materials, light
industry, food, textile industry.
Coal Gas Gasifier Working Principle
Solid coal can be gasified into coal gases through this coal gas gasifier. This coal gas is then dedust and conveyed through a pipe to burn at a nozzle. The coal gas gasifier can provide a much more cheaper heat source.
Coal Gas Gasifier Technical Data
Name | Coal gasifier | ||||||||||
Internal Diameter(m) | 0.6 | 0.6 | 1 | 1.2 | 1.4 | 1.6 | 1.8 | ||||
Sectional Area(m³) | 0.28 | 0.5 | 0.78 | 1.13 | 1.53 | 2 | 2.54 | ||||
Fuel Consumption(kg/h) | 60-90 | 100-130 | 150-210 | 220-265 | 250-300 | 350-450 | 480-580 | ||||
Gas Production(Nm/h) | 180/270 | 300/270 | 450/630 | 600/295 | 750/900 | 1050/1350 | 1440/1740 | ||||
Cleaner Way | Hand Cleaner | ||||||||||
Internal Diameter(m) | 2 | 2.2 | 2.4 | 2.6 | 2.8 | 3 | 3.2 | ||||
Sectional Area(m³) | 3.14 | 3.29 | 4.52 | 5.3 | 6.15 | 7.06 | 8.03 | ||||
Fuel Consumption(kg/h) | 600-850 | 900-1000 | 1000-1200 | 1200-1500 | 1600-1800 | 2400-2600 | 2400-2600 | ||||
Gas Production(Nm/h) | 1800/2550 | 2700/3000 | 3000/3600 | 3600/4500 | 4800/5400 | 6000/7200 | 7200/7800 | ||||
Cleaner Way | Machine Cleaner | Worm Gear | |||||||||
Fuel Standard | anthracite,bitumite, lignite,coke | ||||||||||
Gasification Agent | Gas + Water | ||||||||||
Gas Caloricity(Kj/nm) | 5025-5650(1200-1450 Kcal) | ||||||||||
Gas Outlet Temperature( | 200-450 Can be adjusted according to the coal quality situation) | ||||||||||
Gas Outlet Pressure(Pa) | 900 | ||||||||||
Saturation Temperature() | 45-70 | ||||||||||
Quality Of Coal | <70 | ||||||||||
Working Pressure | Heat should be over 6000 Kcal,Per kilogram of coal can produce three cubic coal gas | ||||||||||
Coal Gas Gasifier Main Advantages
[1] Save 20% coal energy than the direct burning, high heat efficiency.
[2] Coal gas gasifier is easy, safe to operate and quick start.
[3] Coal gas gasifier has a significant effect of dust collection, protect environment.
[4] Coal gas gasifier can improve the labor environment obviously, reduce the labour
intensity.
[5] Oxidation resistant,anticorrosion,Resistance to elevated temperature and long service life.
[6] Convenient installation.
If you need detailed information of coal gas gasifier
Please contact Elva at any time
Hope we can establish a good relationship in the near future
