Good Quality Generator Coal Gasifier

Specifications

Generator Coal Gasifier
1.Lower Fuel Consumption
2.Working Stable
3.Large Coal Gas Output
4.High Caloric Value

 Generator Coal Gasifier Brief Description



Generator coal gasifier which designed and manufactured by GUOXIN factory use air and steam as the gasifying agent, the applicable coal can be blind coal, bituminous coal and so on.



CG generator coal gasifier is the advanced equipment. It's widely used in machinery, metallurgical, chemical, glass, building materials, light

industry, food, textile industry.







Generator Coal Gasifier Working Principle



Solid coal can be gasified into coal gases through generator coal gasifier. This coal gas is then dedust and conveyed through a pipe to burn at a nozzle. The generator coal gasifier can provide a much more cheaper heat source.



Generator Coal Gasifier Technical Data



Name	Coal  gasifier
Internal Diameter(m)	0.6		0.6	1	1.2	1.4		1.6	1.8
Sectional Area(m³)	0.28		0.5	0.78	1.13	1.53		2	2.54
Fuel Consumption(kg/h)	60-90		100-130	150-210	220-265	250-300		350-450	480-580
Gas Production(Nm/h)	180/270		300/270	450/630	600/295	750/900		1050/1350	1440/1740
Cleaner Way	Hand Cleaner
Internal Diameter(m)	2	2.2		2.4	2.6	2.8		3		3.2
Sectional Area(m³)	3.14	3.29		4.52	5.3	6.15		7.06		8.03
Fuel Consumption(kg/h)	600-850	900-1000		1000-1200	1200-1500	1600-1800		2400-2600		2400-2600
Gas Production(Nm/h)	1800/2550	2700/3000		3000/3600	3600/4500	4800/5400		6000/7200		7200/7800
Cleaner Way	Machine Cleaner						Worm Gear
Fuel Standard	anthracite,bitumite, lignite,coke
Gasification Agent	Gas + Water
Gas Caloricity(Kj/nm)	5025-5650(1200-1450 Kcal)
Gas Outlet Temperature(	200-450 Can be adjusted according to the coal quality situation)
Gas Outlet Pressure(Pa)	900
Saturation Temperature()	45-70
Quality Of Coal	<70
Working Pressure	Heat should be over 6000 Kcal,Per kilogram of coal can produce three cubic coal gas





Generator Coal Gasifier Main Advantages



[1] Save 20% coal energy than the direct burning, high heat efficiency.



[2] Generator coal gasifier is easy, safe to operate and quick start.



[3] Generator coal gasifier has a significant effect of dust collection, protect environment.



[4] Generator coal gasifier can improve the labor environment obviously, reduce the labour

     intensity.



[5] Oxidation resistant,anticorrosion,Resistance to elevated temperature and long service life.



[6] Convenient installation.





If you need detailed information of generator coal gasifier



Please contact Elva at any time



Hope we can establish a good relationship in the near future
