Specifications
Coal Gasifier Factory1.Low Coal Consumption
2.Working Stable
3.Large Coal Gas Output
4.High caloric value
Coal Gasifier Brief Description
Coal gasifier which designed and manufactured by GUOXIN factory use air and steam as the gasifying agent, the applicable coal can be blind coal, bituminous coal and so on.
CG coal gasifier is the advanced equipment. It's widely used in machinery, metallurgical, chemical, glass, building materials, light
industry, food, textile industry.
Coal Gasifier Working Principle
Solid coal can be gasified into coal gases through this coal gasifier. This coal gas is then dedust and conveyed through a pipe to burn at a nozzle. The coal gasifier can provide a much more cheaper heat source.
Coal Gasifier Technical Data
Name | Coal gasifier | ||||||||||
Internal Diameter(m) | 0.6 | 0.6 | 1 | 1.2 | 1.4 | 1.6 | 1.8 | ||||
Sectional Area(m³) | 0.28 | 0.5 | 0.78 | 1.13 | 1.53 | 2 | 2.54 | ||||
Fuel Consumption(kg/h) | 60-90 | 100-130 | 150-210 | 220-265 | 250-300 | 350-450 | 480-580 | ||||
Gas Production(Nm/h) | 180/270 | 300/270 | 450/630 | 600/295 | 750/900 | 1050/1350 | 1440/1740 | ||||
Cleaner Way | Hand Cleaner | ||||||||||
Internal Diameter(m) | 2 | 2.2 | 2.4 | 2.6 | 2.8 | 3 | 3.2 | ||||
Sectional Area(m³) | 3.14 | 3.29 | 4.52 | 5.3 | 6.15 | 7.06 | 8.03 | ||||
Fuel Consumption(kg/h) | 600-850 | 900-1000 | 1000-1200 | 1200-1500 | 1600-1800 | 2400-2600 | 2400-2600 | ||||
Gas Production(Nm/h) | 1800/2550 | 2700/3000 | 3000/3600 | 3600/4500 | 4800/5400 | 6000/7200 | 7200/7800 | ||||
Cleaner Way | Machine Cleaner | Worm Gear | |||||||||
Fuel Standard | anthracite,bitumite, lignite,coke | ||||||||||
Gasification Agent | Gas + Water | ||||||||||
Gas Caloricity(Kj/nm) | 5025-5650(1200-1450 Kcal) | ||||||||||
Gas Outlet Temperature( | 200-450 Can be adjusted according to the coal quality situation) | ||||||||||
Gas Outlet Pressure(Pa) | 900 | ||||||||||
Saturation Temperature() | 45-70 | ||||||||||
Quality Of Coal | <70 | ||||||||||
Working Pressure | Heat should be over 6000 Kcal,Per kilogram of coal can produce three cubic coal gas | ||||||||||
Coal Gasifier Main Advantages
[1] Save 20% coal energy than the direct burning, high heat efficiency.
[2] Coal gasifier is easy, safe to operate and quick start.
[3] Coal gasifier has a significant effect of dust collection, protect environment.
[4] Coal gasifier can improve the labor environment obviously, reduce the labour
intensity.
[5] Oxidation resistant,anticorrosion,Resistance to elevated temperature and long service life.
[6] Convenient installation.
If you need detailed information of coal gasifier
Please contact Elva at any time
Hope we can establish a good relationship in the near future
