Semi-flexible RG405 Cable Assembly with MMCX Male Connectors
USD $1.19 - $1.66
/ Piece
100 Pieces(Min.Order)
- 60000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card PayPal
You May Like
-
Semi-rigid Mutil-Angle RG405 Cable Assembly with SMA Male to SMA Male Right Angle Connectors
-
Semi-rigid RG405 Cable Assembly with SMA Male Connectors
-
RG405 Cable Assembly with SMA Male Right Angle to N Female Bulkhead Connectors
-
RG405 Cable Assembly with MMCX Male Right Angle Connectors
-
60mm RG405 Cable Assembly with SMA Male to MCX Male Connectors
-
RG405 Cable Assembly with SMA RP-Male to MMCX Male Connectors
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Four Star | |
| Model Number | MMCX-JB2-100 | Type | Coaxial | |
| Number of Conductors | 1 |
Product Description
Product Description
| 100mm Semi-flexible RG405 Cable Assembly with MMCX Male Connectors at One Side | ||
| Model No. | MMCX-JB2-100 | |
| Connector Type | A Side:MMCX Connector Male for RG405 Cable | |
| — | ||
| Cable Type(Name) | RG405 Cable | |
| Cable Length | 100mm (Customized Length Available) | |
| Connector Interface | CECC-22340 | |
| Typical Frequency Range | DC-6GHz | |
| VSWR | ≤1.30@DC-6GHz | |
| Intermodulation 3rd (PIM3) | — | |
| Durability | ≥500 cycles | |
| Parts Name | Material | Plating |
| Body | Brass | Au |
| Insulator | PTFE | — |
| Inner Conductor | Phosphor Bronze | Au |
| Coupling Nut | Brass | Au |
| Operating Temperature | _45 ℃-85 ℃ | |
| Weatherproof Rate | IP67 | |
| RoHs (2002/95/EC) | Compliant by exemption | |
