Specifications
Screw Plugging Assembly Machine1.Applied to automatically plug tapping, locking screw and assembling.
2.Capacity:12-13PCS/Min
Screw Plugging Assembly Machine
Quality:
The accessories of the machine adopted FESTO/SMC original pneumatic component, Taiwan HIWIN precision linear guide, and precision module, which are made of S136 , the Mitsubishi PLC , HMI, and other electrical components, which are all using German brand.
Efficiency:
1.Loading material automatically
2.Assembling, locking screw, detecting the slide pressure, leaking lock and floating automatically
3.Unloading the finished product automatically
Intelligence:
It equips with automatic alarming system, which reporting irregular operations and giving the relative solutions in the form of message. It also can induct the incoming materials automatically and point out the lack of materials, predict and record the capacity.
Specification
| Model | ZEUEE-CT01 |
| Capacity | 750PCS/H ( Equal to 25-35 workers efforts) |
| Power | AC220V 50Hz 450W |
| Pressure | 0.4-0.6 Kgf |
| Weight | 300 KG |
| Size | 1800(L)×1000(W) ×1200(H) MM |
Picture of the machine
Picture of product
Packaging: Wooden case Shipping: Sea shipping
Steps of packaging
1. Quality Guarantee Service
2. After-sales service provided: Engineers available to service machinery overseas
3. Product life-long maintenance services
4. Deadline Maintenance Service
5. Telephone hotline about techniques
6. Online Service
Skype: zeueesales
Customers can not only order our equipments by sending us samples and coming up with requirements but also ask our professional technicians to design the machines according to your needs. It can be very flexible.
We provide the best services. For more details, please feel free to contact us.
Shenzhen Zeyu Automatic Equipment Company (ZEUEE) is a high-tech enterprise which specializes in the research and development, manufacturing, marketing, and service of non-standard automatic equipment, We are dedicated to provide automatic solutions with high efficiency, high quality, low cost and fully automatic. The application are widely used in many fields for automatic production such as standard fasteners, metal accessories, automotive electronic components, railway electronic components, aviation electronic components, civil electronic components, household appliance, locks, construction hardware, medical instrument parts, cosmetic assembly and lighter assembly, etc. The automatic solution can effectively solve the increasing severe problems of high cost, poor efficiency, low quality, recruitment difficult and hard management, etc. It also can save resources, increase benefit, and achieve the concept of "Harmony and Win-win".
To know more about us, please visit .
Company overview
Factory
Workshop
Assembly workshop
Our Cooperate partner
Certification:
We are experienced and will offer very high quality, high efficiency, lost cost and strong innovation ability machines. If you have any inquires of our products, please feel free to contact me.
