engraving machine with up/down table, rotary clamp, water cooling system, 1 year warranty SD-5030
- 50 Set / Sets per Month
- Qingdao
- T/T Credit Card PayPal
- DANAPR UV Laser Marking Machines F2010
- 1390 large laser engraving machine window cut paper PVC plating film laser cutting machine, cardboard paper engraving machine
- DANAPR UV Laser Marking Machines F2010 UV laser
- 3D Crystal Laser Engraving Machine
- DANAPR UV Laser Marking Machines F2005 UV laser
- DANAPR UV Laser Marking Machines
Product Details
Condition: | New | Laser Type: | CO2 | Engraving Area: | 500*300mm |
Engraving Speed: | 1000mm/s | CNC or Not: | Yes | Cooling Mode: | Water Cooling |
Applicable Material: | Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Graphic Format Supported: | AI, DST, DWG, DXP, LAS, PLT | Place of Origin: | Shandong, China |
Brand Name: | shendiao | Model Number: | SD-5030 | Dimension(L*W*H): | 1030*940*710mm |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
We value our customers
We value our customers's customers
Focus on superior product
Look forward to your pleasure cooperation
engraving machine with up/down table, rotary clamp, water cooling system, 2 years warranty
Laser Engraving Machine Feature:
1. High C/P Value: High capacity and low price suit to initiate laser engraving machine user.
2. Motorized Auto Focus Module: Provide convenient laser beam auto focus function.
3. Pass Through Design: Convenient for continuous feeding process of long material front to rear.
4. Easy Maintain Design: Easy open able side covers make maintenance easier.
5. Motorize Working Table: Provide up to 300mm space for thick material.
6. Aluminum Table With Honeycomb Unit: East & convenient to place and pick engraving work pieces.
7. Fast Engraving Speed: Provide up to 1000mm/s (39.35inch/s),high accurate engraving speed.
Specification:
Model | SD5030 laser engraving machine | ||||
Laser Tube Power(standard) | 40w | ||||
Laser Tube Power(optional) | 50w | ||||
Work Area(mm) | 500*300mm | ||||
Gross power | 1000w | ||||
Laser type | CO2 Laser tube | ||||
Max Engraving speed | 1200mm/s | ||||
Resetting positioning accuracy | <0.01mm | ||||
Minimum forming character | 1x 1mm | ||||
Power supply | 220V±10% 50HZ or 110V±10% 60HZ | ||||
Software supported | Direct output software: CorelDraw, AutoCAD, LASERCUT Design software: PhotoShop, ArtCut, Adobe Reader | ||||
Picture Formats Supported | PLT/DXF/BMP/AI (Direct output) JPG,GIF,PGN,TIF(Conversion output) | ||||
Engrave Curve surfaces | Rotary clamp tool (optional) | ||||
Water Cooling | Yes | ||||
Maximum Height of Material | 150mm(Motorized Up-down adjustable) | ||||
Laser tube | 1200-1500 hours | ||||
Weight | N.W.: 84KGs, G.W:130KGs | ||||
Machine Dimension | 900x690x580mm | ||||
Packing Dimension | 1060x830x880(Wooden box) | ||||
Certificate | CE and FDA | ||||
Assistant Equipment: | Water pump | Air pump | Exhaust Fan | Motorized honeycomb table | |
Optional Accessory: | Red dot pointer | Rotary Clamp | Auto Focus | Water chiller | Purifier & Filter deivce |
Cutting and Engraving materials: Bamboo, jade, marble, glass, crystal, plastic, garments, paperleather, rubber, ceramic, Hard Wood, MDF, Plywood, Plexiglas, Plastic, Acrylic, and othe non metal materials. Can also engrave onto metals with the use of an additive laser marking material like "Cermark".
Applications of laser machines:
Advertising, arts and crafts, leather, toys, garments, model, embroidery, clipping, packaging and paper industry, Wood Working, engraving embroidery, crafts, RC airplanes, balsa models, kites, robotics kits, and clothing patterns.
sample
details
Our Package Advantage:
1.Our wooden case is after fumigation treatment.Needn’t timber inspection,saving shipping time.
2.All the spare parts of the machine were covered by some soft materials,mainly using pearl wool.
Avoiding all damages that could happen in the delivery process.Then we’ll covered plastic wrap out it tightly,make sure intact of the covered soft materials,also avoiding Waterproof and rust proof. 3.The outmost is wooden case with fixed formwork. 4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.
Guarantee and after-sales service:
1. one year equipment warranty and maintenance for lifetime.
2. Free installation and test before sending and free training for operators.
3. Advice for the solutions best for customers requirements.
4. 24 hours technical support by e-mail, calling or door-to-door service.
5. English software, user manual and detailed Videos CD.
Jinan Shendiao Mechanical Equipment Co.,Ltd is known for excellent service and bringing forth laser products that are the best quality of all Chinese laser cutting machines. This equipment can be applied to many kinds of materials, and has many advantages, such as smooth cutting edges, free from polishing, no noise, no dust, faster processing speed, higher precision, less waste and more efficiency. It is the best option for upgrading traditional equipment in various industries.
If custom ordering a machine, the color can also be specified.
How to get the most suitable machine and best price?
please tell us:
the material you wanna handle the max size of these materials(length,width and thickness the work you wanna handle with this machine(engraving ?cutting ?or other)
How long is the delivery time?
A.For standard machines, it would be 7-10 days;
For nonstandard machines and customized machines according to clients specific requirements, it
would be 15 to 30 days.
Do you arrange shipment for the machines?
A:Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
What’s the guarantee?
A:1. Laser tube guarantees 12 months. While the whole machine guarantee for 1 year.
2. 24 hour’s technical support by email or calling.
3. English manual and video tutorial.
4. one year quality guaranty for the machine (excluding the consumables).
5. Lifetime maintenance free of charge.
6. We will provide the consumable parts at an agency price.
7. 12 hours on line service each day, free technical support.
How do I know that I have all the goods I ordered before the shipment?
We will make pictures for every part of the goods in order.and the pictures will be sent to our clients for confirmation before the shipment.
How can I get Machine's spare parts?
There are two methods.
You can order the spare parts together with the machine,
this is the safest way to transport the laser tube.
The other way is you can inform us when you need to replace the consumables,we will send as soon as possible.
Which parts of the machine are also expendable?
The wearing parts of machine are laser tube, lens and reflectors
Welcome to our company personally,we are very appreciated it if you are interested in our products.
Please contact us at your convenience.Thank you very much for your reply.
