SD-4040 Mini and Desktop Laser machine
1. Suitable for small area craft processing.Engraving varies graphics and letter on double color board, wood, bamboo, organic glass, clothing, leather etc. 2. Suitable for engraving on non-metal materials, all kinds of stamp, like horn, wooden,red plastic, organic glass etc. 3. Carve name, model, label, design and date on electronic parts. 4. Cut acrylic and organic glass.
Samples
Model |
SD-4040 |
||
Working area |
400*400mm |
||
Laser Power |
40W |
||
Laser Type |
CO2 sealed glass Laser Tube |
||
Engraving speed |
Lasercut software: 0-1000mm/s Newlydraw software: 0-500mm/s |
||
Worktable |
Aluminum section worktable with T-slot |
||
Resetting positioning accuracy |
<0.01mm |
||
Cutting depth(mm) |
Acryl 0-10 (differs on different materials) |
||
Minimum Shaping Character |
1×1mm |
||
Power supply |
220V±10% 50HZ or 110V±10% 60HZ |
||
Software supported |
ArtCut, CorelDraw, PhotoShop, AutoCAD |
||
Graphic format supported |
PLT,DXF,BMP,JPG,GIF,PGN,TIF |
||
Water Cooling(Yes / No) |
Yes |
||
Maximum Height of Materials to Engrave (mm) |
25mm |
||
Laser Tube (life hours) |
1200-1500 hours |
||
Assistant Equipment |
Water pump |
Water follow sensor |
Exhaust fan |
Optional Parts |
Red dot pointer |
Water chiller |
Honeycomb cutting table |
Consumables |
Lens and mirror, laser tube |
||
Certificate |
CE |
||
Optional
Warranty and service:
1.Free consultation service before,during,and after-sales;
2.Free project planning and design services;
3.Providing one year complete warrantee and life-time maintenance service;
4.We are online for 24-hour every day, if any questions, you can contact us easily.
1.Our wooden case is after fumigation treatment.Needn’t timber inspection,saving shipping time.
2.All the spare parts of the machine were covered by some soft materials,mainly using pearl wool.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.
Jinan Shendiao Machinery Equipment Co., Ltd is the professional manufacturer and exporter of mechanical CNC router machine, laser machine and other relevant equipment. Our products are widely used in various industries. We have granted our own brand "Shendiao" or "SD". By reason of high quality products and top after-sales service, we have won trust and support of customers from all over the world.
In order to help you choose the best suitable machine,can you reply my questions below, thank you.
Q1: What about your material , wood or acrylic or ?
Q2: The size of your material , length, width and thickness?
Q3: Do you want to cut or engrave your material ? Or both cut&engrave ?
Q4: What machining effect do you want to get ? It is better for me if you can send sample pictures to me .
Q5: The machine chooses 220v or 110v or ?
Q6: What is the nearest seaport to you?
Contact info
Name:JannyLei
Skype;jannylei1994
website:
We also have many different working size, such as 1200*900mm, 1300*2500mm,600*900mm, 1300*900mm,1400*900mm, 500*300mm, 1600*2500mm etc. And we can manufacture machines that can meet the customers' requirements
Different machine working area :
| Machine model | Working area(mm) |
| SD-5030 | 500mm*300mm |
| SD-6040 | 600mm*400mm |
| SD-9060 | 900mm*600mm |
| SD-1290 | 1200mm*900mm |
| SD-1390 | 1300mm*900mm |
| SD-1410 | 1400mm*1000mm |
| SD-1325 | 1300mm*2500mm |
| SD-1630 | 1600mm*3000mm |
Please contact us at your convenience.Thank you very much for your reply.
