Specifications
jeans laser engraving machine1.laser engraving logo,photo,whisker
2.high speed 20000mm/s
3.CO2 RF metal laser
4.auto feeder
Germany Galvo Head Denim Jeans Laser Engraving Machine
<<Jeans Laser Engraving Machine, Demo Video: http://youtu.be/W76KfjtLozc
Features of Golden Laser Engraving for Jeans/Denim:
1, Any intricate patterns can be engraved, such as portrait, flower, letter and other patterns, high-speed, real, natural, attractive.
2, Embroidered applique can be kiss-cut, no damage to the underlying fabric.
3, Delicate engraved designs. Textured, image, gradient and many other effects can be created.
4, Color of engraving designs do not fade. Cutting or punching fabric edge without fringe
5, Golden Laser unique Large format Galvanometer engraving.
Denim Jeans Laser Engraving Principle:
Laser engraving, high intensity laser emitted from laser generator. Its motion curve is controlled by advanced Galvo system and CNC system. The inherent color of denim jeans appears resulting from high temperature gasification of the denim fabrics surface. Hollowing and punching process can be achieved as well. Therefore, various novel & magical patterns with different shades, different texture and layering will be come out.
Laser Galvo Engraving System - FAST FASHION AND ECOLOGICAL ENGRAVING FOR DENIM JEANS
WHY LASER FOR JEANS INDUSTRY?
Compared with traditional WASHING WAY or LAUNDRY machine, laser engraving has its advantage to lead in the jeans industry development.
|
Design |
Procedure |
Process time |
Labor Cost |
Process Way |
Environment |
Laser engraving |
Any design |
Simple operation process |
4 seconds for whisker design |
One operator |
Any effect processed |
No pollution |
Chemical Washing |
Simple |
Complicated procedure |
Long time production |
Many workers |
Change different chemicals |
Chemical pollution |
ZJ(3D)-125125LD Galvo Laser Engraving Machine for Jeans
You can finish 60,000-80,000 jeans per month
by our Laser Engraving Machine!!!
Jeans Laser Engraving Machine,Working Flow Profile:
@Feeding station with the projector→3 axis dynamic galvanometer processing station→Loading station
@Feeding station with the projector: The operator put the jeans on the conveyor belt working table within the outline area of projector, press the foot switch, the machine will be feeding.
@3 axis dynamic galvanometer processing station: After feeding stop, the system automatically start processing the required design, waiting for the next feeding signal.
@Loading station: The finished engraving jeans will be loading through the conveyer belt, and loaded into container
Laser Engraving Machine for Jeans,Process Features:
a. Compared with the traditional washing, laser process without chemical and less pollution;
b. With continuous feeding method, it overlaps the process and loading/unloading time, improves the working efficiency;
c. Adopts with CNC process, Easy patterns and designs change way and stable performance;
d. Equipped with high-power RF laser tube, it comes with more stable power, lower cost maintenance and higher efficiency;
e. Patented exhaust system ensures the exhaust effect of large working size engraving;
f. This system is safe and reliable with closed optical path;
g. Professionally designed out view, friendly interface, Easy Operation.
ZJ(3D)-125125LD jeans laser engraving machine | |||
Laser Generator and Optic parameters | |||
Laser Type |
CO2 RF metal laser |
Laser Power |
500W |
Laser Wavelength |
10.6 micro meters |
Galvo effective area |
1100mm*1100mm |
Galvo process speed |
0-20000mm/s (defined as the process material and requirement) |
||
Software system | |||
Control software |
Goldenlaser original software |
||
Software Format |
BMP, AI, DST, DXF, PLT, etc. |
||
Working table parameter | |||
Working table type |
Transport conveyer belt |
||
Conveyor speed |
0-600 mm/s |
Conveyor table motor |
Servo motor |
Assistant System | |||
Protection System |
Full protection with optic part structure |
||
Control System |
GoldenLaser III control card |
||
Cooling System |
Constant temperature water chiller 5KW for laser machine |
||
Exhaust System |
Fixed Upper exhaust fans (Filter system is optional) |
||
Model No. |
Laser Power |
Time for whisker design (front position of left and right) |
Time for monkey washing effect (front position of left and right) |
Productivity for monkey wash effect |
Advantage |
ZJ(3D)-125125LD |
500W |
4 second/jeans |
18 second/jeans |
81000 pcs/per month (12 hours/30 days) |
A line of more jeans on conveyer table for continuous production |
Note: The actual process time depends on the processed design, laser power, software parameter setup.
Jeans Laser Engraving Samples Gallery:
Golden Laser - Overview:
Goldenlaser is a manufacturer of different types (CO2, YAG, and Fiber) laser cutting, engraving systems, suitable for different industries - flexible textile, solid advertising, metal processing and Printing & packing. Whether you need a cost-effective machine or a more sophisticated automated solution. From the economical models to the large format processing systems, GoldenLaser has the laser machine solution that meets your requirements.
