For fabric acrylic laser engraving cutting machine SD-5030
small laser cutter and laser engraver
This laser machine is suitable for many kinds of non-metal materials, such as wood, bamboo, acrylic, organic glass, crystal, plastic,double-color board, marble, ceramic, glass, horn, paper, rubber, leather and so on.
Features
1. Modern smart design. Put on table and work easily. 2. Stronger frame together with HIWIN square rail, high accuracy. 3. Red cross point offers the highest accuracy position. 4. High efficiency tube with stable laser path. 5. Professional motion control card offers continue fast curve cutting together with shortest path selection. Shorten work time. 6. U disk offline operation makes work convenient.
Parameters:
Model |
SD5030 |
||||
Laser Tube Power(standard) |
40w |
||||
Laser Tube Power(optional) |
50w |
||||
Work Area (mm) |
500*300mm 19.69"x11.81'' |
||||
Gross power |
1000w |
||||
Laser type |
CO2 Laser tube |
||||
Max Engraving speed |
1200mm/s |
||||
Resetting positioning accuracy |
<0.01mm |
||||
Minimum forming character |
1x 1mm |
||||
Power supply |
220V±10% 50HZ or 110V±10% 60HZ |
||||
Software supported |
Direct output software: CorelDraw, AutoCAD, LASERCUT |
||||
Design software: PhotoShop, ArtCut, Adobe Reader | |||||
Picture Formats Supported |
PLT/DXF/BMP/AI (Direct output) JPG,GIF,PGN,TIF(Conversion output) |
||||
Engrave Curve surfaces |
Rotary clamp tool (optional) |
||||
Water Cooling |
Yes |
||||
Maximum Height of Material |
150mm (Motorized Up-down adjustable) |
||||
Laser tube |
1200-1500 hours |
||||
Weight |
N.W.: 84KGs, G.W:130KGs |
||||
Machine Dimension |
900x690x580mm |
||||
Packing Dimension |
1060x830x880(Wooden box) |
||||
Certificate |
CE and FDA |
||||
Assistant Equipment: |
Water pump |
Air pump |
Exhaust Fan |
Motorized honeycomb table |
|
Optional Accessory: |
Red dot pointer |
Rotary Clamp |
Auto Focus |
Water chiller |
Purifier & Filter deivce |
parts
Applicable Industry:
| Materials | Engrave | Cut |
| Wood/wood veneer/MDF/Plywood/Bamboo/Cork | YES | YES |
| Acrylic/Double color board/PVC and other advertising materials | YES | YES |
| Leather/PU/PVC leather/Canvas | YES | YES |
| Fabric/Cloth/Curtain/Twill | YES | YES |
| Paper/Postcard/Card paper/Mat board | YES | YES |
| Plastic/Mylar | YES | YES |
| Rubber | YES | YES |
| Figerglass | YES | YES |
| Delrin/Melamine | YES | YES |
| Corian | YES | YES |
| Anodized aluminum | YES | NO |
| Painted metals/Coated metals | YES | NO |
| Tile/Ceramics/Brick | YES | NO |
| Marble/Stone/Granite | YES | NO |
| 0.5mm-1mm stainless steel | NO | YES |
Samples
Package Advantage:
1.Our wooden case is after fumigation treatment.Needn’t timber inspection,saving shipping time.
2.All the spare parts of the machine were covered by some soft materials,mainly using pearl wool.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.
1.FOB----The nearest port is Qingdao port,and we can also delivery the machine to other port according to your request.
2.CIF-------Please tell me what’s the destination port when you need CIF price.
3.If you need others, please tell me and I’d like to make it for you.
Payment terms
T/T, Western Union,L/C or others,for you choice
30% in advance,70% before shipping.
Our service
Warranty and service:
1) One year's Warranty. During the warranty, we will provide you new machine parts for replacing free of charge.(excepting the consumables, such as Lens and Reflectors)
2) 24 hours' Online Technical Service. You can get technical support by Email/Skype/Telephone
3)Easy operation. Working videos, operation manual of the machine are both available.
Company information
Jinan Shendiao Machinery Equipment Co., Ltd is the professional manufacturer and exporter of mechanical CNC router machine, laser machine and other relevant equipment. Our products are widely used in various industries. We have granted our own brand "Shendiao" or "SD". By reason of high quality products and top after-sales service, we have won trust and support of customers from all over the world.
we can manufacture machines that can meet the customers' requirements
FAQ
Q1 : I knew nothing about this machine, what kind of machine i should choose?
Very easy to choose. Just tell us what you want to do by using cnc router/laser machine ,then let us give you perfect solutions and suggestions.
Q2: When i got this machine, but i did not know how to use it.What should i do?
We will send video and english manual with the machine.If you still have some doubts, we can talk by telephone or skype.
Q3: If some problems happend to this machine during warranty period,what should i do?
We will supply free parts in machine warranty period if machine have some problem.While we also supply free after-service forever.
