Auto-loading PET preform
Imported electric & pneumatic parts
Electric box
200-1500ml pet bottle mini blow moulding machine
BST-2500 200-1500ml pet bottle mini blow moulding machine is the most stable two-step automatic stretch blow moulding machine. It has two cavities and the maximum capacity of the products is 2L. It can blow bottles in shapes: carbonated, mineral, pesticide, cosmetics, wide-mouth, hot filling, and other packing containers, which is made of PET
1).High Automatization
2).High Intelligence:The machine can be controlled through touch screen and running status is shown on it.
3).High Quanlity:Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.
4).High Speed:2500BPH(2-cavity) plastic bottle making
5).No Contamination:Closed production zone, good self-lubrication system avoid contamination.
6).Low Cost:Low consumption of electricity, air and water.
7).High Transparency:Easy maintenance, absolute safely, visual inspection, low noise.
Features
A. Stable performance with advanced PLC.
B. Conveying preforms automatically with conveyor.
C. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater stretch moulding machine
D. High adjustability to enable the preheater to preheat preforms in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, 200-1500ml pet bottle mini blow moulding machine and eternal temperature in the preheater with an automatic thermostatic apparatus.
E. High safeties with security automatic-locking 200-1500ml pet bottle mini blow moulding machine in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.
F. No contamination and low noise with the air cylinder to drive the action instead of the oil pump.
G. Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.
H. Strong clamping force with high pressure and double crank links to lock the mold.
I. Two ways of operating: automatic and manual.
J. Safe, reliable, and unique design of the position of valve to make the air pressure diagram of the machine easier to understand.
K. Low cost, high efficiency, easy operation, easy maintenance, etc, with automatic technological process.
L. Contamination is avoided for the bottle body.
M. Ideal effect of the chilling with the chilling system.
N. Easy installation and starting
O. Low rejection rate: less than 0.2 percent.
200-1500ml pet bottle mini blow moulding machine
BST-2500 machine main technical data
Type |
BST-2500 |
|
output |
according to bottle shape |
2000-20PCS/H |
product specification |
bottle body diameter |
20mm-100mm |
bottle height |
50mm-350mm |
|
bottle mouth diameter |
15mm-38mm |
|
mold |
cavity |
2cavities |
mold thickness |
180mm |
|
mold effective area |
350*350mm |
|
Main power |
power ,voltage |
380v 3Phase /220v 3Phase 50/60HZ |
Install machine power/actural use power |
30kw/15kw |
|
air source |
low pressure air compressor |
1.6m3/min 1.0MPa |
high pressure air compressor |
2.0m3/min 3.0MPa |
|
cold-dry machine |
2.0m3/min 3.0MPa 1set |
|
cooling water |
cooling quantity |
15L/min |
main machine size |
Length*width*height/weight |
1908*1858*1920mm/3000kg |
feeder size |
Length*width*height/ weight |
2000*950*2480mm/250kg |
