FU2030 Multifunction Power Meter
FU2030 is a LED display power analyzer, metering and displaying all the measured parameters in one circuit and computing four quadrants energy. This model can work in wide temperature range.
Measurement Parameters
Voltage (Ph-N); Voltage (Ph-Ph); Current; Frequency; PF; Active Power(W); Reactive Power(Q) ; Apparent Power(S)
Computation
Forward active power energy
Reverse active power energy
Forward active power energy
Reverse reactive power energy
Measuring Range
30~600V, 0~6A, 45~65Hz, -1~0~1
Measuring Accuracy
Frequency: 0.1%
Electric energy: 0.5%, 1.0%
Voltage : 0.2%±0.1V
Current : 0.2%±0.001A
Power : 0.5% ±0.4W
Power Factor : 0.5% ±0.001
Display
LED Display, 4 Displays. 4 operation keys.
Communication
RS-485 interface port support, 32 (128) Networking, ModBus-RTU communication protocol.
Analog Output (Expansion module)
DC 4~20mA output, programmable to any measured parameters.
Connection Mode
3P4W, 3P4W BAL, 3P3W, 3P3W BAL, 1P2W, 1P3W.
Programmable
Measuring System : 3P4W/3P3W etc.
Transformation Ratio : PT,CT.
Communication:
Address: 1~247; Baud: 1200~19200; Parity Bit: N/E/O
Energy: Reset
Dimension
Mounting Panel:120 X 120mm
Thickness:21mm
Depth:118mm
Mounting
Panel Mounting
Trepanning: 92 X 92mm
Power Supply (AC/DC)
AC85~265V / DC85~330V
Power Consumption: <6VA
Working condition
Temperature: -25 ~ 55 °C
Humidity: 20% ~ 95%RH, Without condensation
