High Frequency Fuse Category:
High frequency fusing machine mainly divided into automatic Rotary High Frequency Fuse (optional automatic reclaimer robot), automatic sliding desktop high frequency fusing machine, fusing machine manually push the disc, double-high frequency fusing machine, high frequency synchronous fusing machine fixed disc several. Commonly referred to as high frequency fusing machine, high frequency fusing machine, high frequency synchronous fusing machine, fusing machine, high frequency synchronous cutting machine, cutting machine high frequency, high frequency synchronous fusing machine!
Second, high frequency fusing machine features:
1, the machine uses low-loss coaxial European standard high-frequency resonators, high frequency electrical power output, in the most rapid time to make welding products, and greatly increase production.
2, Kai Austrian high frequency fusing machines are equipped with special high frequency fusing mold, has a good effect of welding cutting, fusing mold are fundamentally different high frequency fusing mold with other companies in general, that is fusing machine mold more durable than ordinary fuse module , no need to replace the bottom die, never worn. Fuse Die sustainable use of approximate 100,000 times.
3, automatic sliding desktop high frequency fusing machine Taiwan motor drive, precise positioning station. Fuse with a NL-5557 high-frequency spark protection system, high sensitivity, high frequency mold to prevent burning. And a high-frequency frequency stabilizer and high frequency shielding devices, the high-frequency interference to a minimum, to avoid radio interference. And will avoid improper operation by the frequency drift caused by the electrode and material damage to a minimum while warning lights are illuminated warning.
4, automatic sliding desktop high frequency fusing machine oscillation frequency in line with international standards for industrial band, high-frequency electromagnetic field generated by a high Q value vacuum tube self-excited oscillator, so that the processing of plastic in high frequency electric field between the upper and lower electrodes to generate intense molecular motion friction in the mold under pressure to get its welding results. High frequency fusing machine uses H-gantry structure, about two-way automatic sliding Taiwan, and from the continuous push mold, efficient operation.
Third, automatic sliding desktop high frequency synchronous fusing machine machine uses:
Mainly used for processing high-frequency welding needs to be synchronized at the same time cutting the working principle is the use of high-frequency machine high frequency welding through the first machine with some pressure device and cut off. Because it is at the same time to complete, so called high frequency synchronous fusing machine. Also known as high frequency fusing machine, fusing machine, high frequency synchronous cutting machine, high frequency cutting machine. Mainly applicable to APET, PETG, GAG environmentally friendly materials double-sided blister sealing packaging, blister card packaging paper, toothbrush sealed packaging, as well as EVA leather cloth, leather, OPP, PU, straps, lanyards, water bottle, thermal bags and other needs but also synchronous fusing welding products.
Fourth, automatic sliding desktop high frequency synchronous fusing machine specifications:
Model: QO-5KWDZ QO-8KWDZ QO-10KWDZ QO-12KWDZ QO-15KWDZ
High Frequency Power: 5000W 8000W 10000W 12000W 15000W
Power supply voltage: 380V 50 / 60HZ
Frequency: 27.12MHZ 27.12MHZ
Input power: 8KVA 15KVA 18KVA 20KVA 25KVA
Rectifier: Silicon diode
Oscillating tube: 7T85RB 7T69RB E3069RB E3130RB 8T85RB
Maximum pressure: 5T 10T 15T 20T 25T
Electrode spacing: 200mm
Activities Dimensions: 100mm
The electrode size: 300 * 400mm 300 * 500mm 350 * 500mm 400 * 500mm 400 * 600mm
The lower electrode size: 300 * 450mm 300 * 500mm 350 * 500mm 400 * 500mm 400 * 600mm
Welding time: 0 --- 10sdjustable
Welcome to buy Biopolis automatic sliding desktop high frequency synchronous fusing machine, a variety of equipment can also be customized according to customer requirements! Because improvement needs, specifications and price without notice!
