China Products Promotional Price High Frequency Embosser
- SHENZHEN
You May Like
-
China Wholesale hf Welding Machine 25kw
-
China Wholesale Hot Sale Foot Pad Making Machine
-
China Wholesale Superior Service Ceiling Welding Machine
-
China Wholesale Good Reputation Car Mat Welding Machine
-
China Wholesale Quality Assurance Bath Mat Making Machine
-
China Wholesale Excellent Quality Logo Embossing Machine
Product Details
| Place of Origin | Guangdong, China | Brand Name | QO | |
| Model Number | QO-8KWSTY | Voltage | 220V 50/60HZ | |
| Power | 8KW | Frequency | 27.12MHZ | |
| Welding Area | 180cm2 | Dimensions | 1600*1200*1860mm | |
| Weight | 350-1500KG | Usage | PVC welding | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
china products promotional price high frequency embosser
QO-**KWSTY:
First, push Hydraulic High Frequency machines, hydraulic high-frequency machine structural characteristics:
1, manually push the disc high-frequency machine and ordinary manual hydraulic push the disc main difference is the pressure part, this class mining models have a hydraulic station pressure, steady pressure, velocity uniformity, suitable for demanding need for a balanced pressure products.
2, push the disc high-frequency machine with single head push plate sliding desktop operation, the table panel is divided into left and right sides of the push plate plate, the operation mode is driven by the operator about slide, push plate on both sides alternately pushed the nose down to the use of welding .
3, high frequency welding process is fully controlled by time, the device has a four-time, control the rise time, fall time, welding time, really cold time.
4, high frequency welding machine mainly driven by two linear guide cylinder operation principle of pulling down movement of the electrode plate, when the product is in place, push down on the electrode, when compacted cast high cycle welding, to weld time, the nose electricity and board rose again to the standby state.
5, push Hydraulic High Frequency machines, hydraulic high-frequency machine output and high-frequency current is strong, stable and reliable performance, the head according to the required air pressure may heat welding of plastics, plastic material sealed packaging requirements adjustable.
6, the nose push reel high frequency welding machine is mainly used flatbed mode installation mold, mold only needs to be fixed on a flat, simple, flat-head of the main advantages is mainly for high frequency mold larger area Plastic, plastic products, heat welding or blister sealing.
Second, push Hydraulic High Frequency machines, hydraulic high-frequency machine electrical characteristics:
1, high frequency machine with automatic over-current protection system, when the high-frequency current load exceeds the limit value, high-frequency machine will automatically cut off the high frequency, high frequency mechanical electronic oscillator tube protection from damage, avoid high-frequency frequency caused by the improper operation of the drift, so High Frequency die and material damage to a minimum.
2, Kai Austrian high frequency welding machine with high-Q electronic oscillation tubes, international industry standard high frequency 27.12MHz frequency band, large output is more stable, the output rate is particularly strong, can greatly reduce the high-frequency welding time, improve product quality and yield.
3, high frequency welding machine plastic material provided with NL5557 high sensitivity spark protection, accurate detection of current imbalance sparks, and when spark current increases, can quickly cut off in an instant spark oscillation circuit suppressed, making molds, Damage raw materials and products to a minimum.
4, assembly oscillating current adjustment device to adjust the output power of the same tune, regulators easy, according to product size and material thickness to set the desired frequency current, you can control the degree of high-frequency welding, welding quality to ensure product uniformity , aesthetics.
Third, push Hydraulic High Frequency machines, hydraulic high-frequency machine specifications:
Model | QO-5KWSTY | QO-8KWSTY | QO-12KWSTY | QO-15KWSTY | QO-25KWSTY |
Output Power of Generator | 5000W | 8000W | 10000W | 15000W | 25000W |
Anti-Spark System | NL-5557 High sensitive anti-spark system(Optional) | ||||
Voltage | 3P AC 380V/220V 50Hz-60HZ or customize | ||||
Frequency | 27.12MHz +/- 0,6 % | 13.56MHz +/- 0,6 % | |||
Input power | 8KVA | 15KVA | 20KVA | 25KVA | 35KVA |
Rectifier | SILICON DIODE |
| |||
Oscillation tube | 7T85RB | 7T69RB | E3130 | 8T85RB | 8T25RA |
Max pressure | 1T | 1.5T | 3T | 5T | 10T |
Operation mode | Manual or motorized | ||||
Max gap of electrodes | 200mm | ||||
Activities size | 100mm | ||||
Upper Electrode (L*W) | 350*200mm | 600*400mm | 700*500mm | 800*600mm | 1000*800mm |
Size of Work Table (L*W) | 450*300mm | 800*600mm | 850*650mm | 900*700mm | 1100*900mm |
Welding time | 0.01~9.99s adjustable | ||||
Net weight | 450kgs | 600kgs | 800kgs | 1000kgs | 1500kgs |
Welcome Biopolis push Hydraulic High Frequency machines, hydraulic high-frequency machine, a variety of equipment can also be customized according to customer requirements! Because improvement needs, specifications and price without notice!
