This machine is automatic rotary high frequency fusing machine, artificial discharge, the machine automatically spin welding, and synchronized cutting, draw back with automation product, the whole process, except in front of the artificial discharge, after the knot is automatically continuous operation, stable production efficiency, saving manpower and resources, the effective control of delivery time.
I. Overview
Automatic disc type high frequency fusing machine, take the product with mechanical automatic high frequency high frequency welding machine is mainly used need to be synchronized at the same time cutting the product processing, the machine is equipped with automatic dial, it can automatically rotate continuously welded, and take the product with a robot automatic production, raw materials can be done manually placed after. Working principle is to use high-frequency machine high frequency electromagnetic flow penetration-promoting molecules, finally fused together, and then through the first welding machine is equipped with some of the pressure device and cut off. Because it is at the same time to complete, so called high frequency synchronous fusing machine. Also known as high frequency fusing machine, fusing machine, high frequency synchronous cutting machine, high frequency cutting machine. Kai Austrian company production of automatic disc type high frequency fusing machine, take the product with mechanical automatic high frequency machine is mainly for mass production, the special needs of the provincial labor needs and the development of high-speed production, can effectively increase production to save resources.
Second, the automatic disc high frequency fusing machine, take the product with mechanical characteristics of automated high-frequency machines:
High frequency fusing machine usually divided; automatic Rotary High Frequency Fuse (optional automatic reclaimer robot), automatic sliding desktop high frequency fusing machine, fusing machine manually push the disc, double-high frequency fusing machine, high frequency synchronous fusing disc set Several machines. The company has specialized in the production. The machine uses low-loss coaxial European standard high-frequency resonators, high frequency electrical power output, in the most rapid time to make welding products and greatly increase production.
High Frequency Fuse need tower with special high frequency fusing molds, in order to achieve the effect of welding cutting, fusing mold are fundamentally different Kai Austrian company's high frequency fusing mold with other companies in general, that is fusing machine mold more durable than ordinary fuse module , no need to replace the bottom die, never worn. Fuse Die sustainable use of about tens of thousands of times.
Automatic rotary high frequency fusing machine with precision divider device, using Taiwan's motor. Automatic rotation, 3-6 stations to choose from, work more efficiently. Four-native job rotation, precise positioning stations. Robot automatic dispensing, synchronous fusing function. Fuse 1--30 tons adjustable cutting pressure, QO-5557 High Frequency spark protection system, high sensitivity, high frequency mold to prevent burning. And a high-frequency frequency stabilizer and high frequency shielding devices, the high-frequency interference to a minimum, to avoid radio interference. And will avoid improper operation by the frequency drift caused by the electrode and material damage to a minimum while warning lights are illuminated warning.
Third, automatic disc high frequency fusing machine, take the product with mechanical automatic High Frequency Usage:
Mainly used for processing high-frequency welding needs to be synchronized at the same time cutting the working principle is the use of high-frequency machine high frequency welding through the first machine with some pressure device and cut off. Because it is at the same time to complete, so called high frequency synchronous fusing machine. Also known as high frequency fusing machine, fusing machine, high frequency synchronous cutting machine, high frequency cutting machine. Mainly applicable to APET, PETG, GAG environmentally friendly materials double-sided blister sealing packaging, blister card packaging paper, toothbrush sealed packaging, EVA cloth to leather, leather, OPP, PU material welding and fusing.
Fourth, automatic disc high frequency fusing machine, take the technical specifications of products with mechanical automatic High Frequency Machine:
Model: QO-8KWDYZ QO-10KWDYZ QO-12KWDYZ QO-15KWDYZ
High Frequency Power: 8000W 10000W 12000W 15000W
Power supply voltage: 380V 50 / 60HZ
Frequency: 27.12MHZ 13.56mhz
Input power: 15KVA 18KVA 20KVA 25KVA
Rectifier: SILICON DIODE silicon diode
Oscillating tube: 7T69RB E3069RB E3130RB 8T85RB
Maximum pressure: 10T 15T 20T 25T
Electrode spacing: 200mm
Activities Dimensions: 150mm
The electrode size: 300 * 400mm 300 * 400mm 350 * 450mm 400 * 500mm
The lower electrode size: 350 * 450mm 350 * 450mm 400 * 500mm 400 * 500mm
Welding time: 0 --- 10sdjustable
Welcome to buy Biopolis automatic disc type high frequency fusing machine, take the product with mechanical automatic high frequency machine, a variety of equipment can also be customized according to customer requirements! Because improvement needs, specifications and price without notice!
