Closed diesel 50kva generator price in supermaly !!!!
The power range of our generating set is from 8KW to 2000KW.It is coupled by world famous brand engine such as PERKINS,CUMMINS,DEUTZ,STEYR,RICARDO,etc,with world famous brand alternator such as STAMFORD,MARATHON,LEROY SOMER,etc.We are the OEM factory of above engines and alternators.
Our products are with advantage of Lower noise,lower vibration,easily starting,reliable performance ,which can be widely used in factories ,mines,banks ,hospitals ,ship building ,telecommunications,oil fields ,buildings,construction fields and other fields ,or used as the standby power.
Closed diesel 50kva generator price e Specification :
| Cummins Series Diesel Generator | ||||||
| Genset Model | Open Type | SC50GF | ||||
| Silent Type | SC50GFS | |||||
| Prime Power(kW/kVA) | 50/62.5 | |||||
| Standby Power(kW/kVA) | 55/68.75 | |||||
| Diesel Engine | Model | 4BT3.9-G2 | ||||
| Type | water-cooled, inline, 4-stroke, direct injection ,wet cylinder liner,1500rpm | |||||
| Rated Power(kW) | 50 | |||||
| Intake Type | Turbocharged | |||||
| No.of Cylinder | 4.L | |||||
| Bore x Stroke(mm) | 102*120 | |||||
| Compression Ratio | 16.5:1 | |||||
| Noise Level (dBA) | 96 | |||||
| Exhaust Temperature(°C) | 475 | |||||
| Lub oil Capacity(L) | 11 | |||||
| Rated Fuel Consumption(L/h) | 11.5 | |||||
| Displacement(L) | 3.9 | |||||
| Governing Type | Electrical | |||||
| Alternator | Model | Chinese | ||||
| Rated Power(kW/kVA) | 50/62.5 | |||||
| Power Efficiency | 88.1% | |||||
| Excitation Type | Brushless | |||||
| Insulation Class | H | |||||
| Overall Size(mm) | Length | 2000 | ||||
| Width | 750 | |||||
| Height | 1300 | |||||
| Gross Weight(kg) | 800 | |||||
Closed diesel 50kva generator price Features:
Exhaust System
Exhaust Gas Flow (after turbo): 14.8m3/min
Exhaust Temperature: 497℃
Max Back Pressure: 10kPa
Air Intake System
Max Intake Restriction: 6.2kPa
Consumption: 5.9m3/min
Air Flow: 158m3/min
Fuel System
100%(Prime Power) Load: 216 g/Kwh
75%(Prime Power) Load: 214 g/Kwh
50%(Prime Power) Load: 221 g/Kwh
100%(Prime Power) Load: 13.8 L/h
Oil System
Oil Consumption: ≤4g/KWhr
Engine Oil Tank Capacity: 14.3L
Min Oil Pressure at Rated RPM: 350kPa
Cooling System
Total Coolant Capacity: 21L
Thermostat: 83-95℃
Max top tank Temperature: 100℃
Control Module:
one two
One:
Standard Control Panel is the basic configuration for normal operation and usage. It is of some advantage such as easy to operate various function and well protection. Operative buttons such as Turn On, Per-heart. Starting, Stop (Emergency Stop) on the panel .while malfunction occurs, control panel will stop the generator and also alarm with light or buzz.
Two:
Automatic Control Panel is the basic configuration for nobody on duty controlling generator. This kind of panel can accept the remote Start/Stop signals.
(Controlled by ATS)
Features: adopted Chinese producing,
Auto control system, with large LCD,
Display in English (or CHINESE) to show the menu. With Auto Control Panel .generator are of various functions such as auto/manual stop (Emergency Stop), programmable plugs for input and output detected data, symbols diagram will show in the LCD, etc.
After sale promise :
1. Since generator set reached the agreed destination, its main parts will be guaranteed within 12 months or 1500 hours.
2. We give technical guide all the service life. In the warranty days, we send spare parts for free. After warranty, we take the spare parts cost.
3. Daily consumed components, wrong operating, lack of maintenance are not include in the quality guarantee.
