2000kva powerful diesel generator open/silent/trailer engine made in UK Price Supplier's Choice
- 500 Set / Sets per Month
- Qingdao
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | supermaly | Model Number: | SP1600GF |
Output Type: | AC Three Phase | Speed: | 1500rpm/1800rpm | Frequency: | 50HZ/60HZ |
Rated Power: | 1600KW/2000KVA | Rated Voltage: | 220V/230V/380V/400V/415V | Rated Current: | 2880A |
Product Description
2000kva powerful diesel generator open/silent/trailer engine made in UK Price for sale Specification :
1. 2000kva diesel generator water cooled uk engine Sale with stamford, Leroy Somer, Marathon ,and China brand alternator .
2.Module you can choose Smartgen ,Deepsea, CoMap.
3.Open type ,silent type , trailer type by option .
4. Warranty 1 year or 1500hours .
5.Standard control panel or automatic control panel by option.
Genset Model | Open Type | SP1600GF | ||||
Silent Type | SP1600GFS | |||||
Prime Power(kW/kVA) | 1600/2000 | |||||
Standby Power(kW/kVA) | 1760/2200 | |||||
Diesel Engine | Model | 4016TAG2A | ||||
Type | water-cooled,inline, 4-stroke,direct injection ,wet cylinder liner | |||||
Rated Power(kW) | 1766 | |||||
Intake Type | Turbocharged | |||||
No.of Cylinder | 16.V | |||||
Bore x Stroke(mm) | 160x190 | |||||
Compression Ratio | 13.6:1 | |||||
Mechanical Governor Rate | 5% | |||||
Electronic Governor Rate | 1% | |||||
Noise Level (dBA) | 103 | |||||
Exhaust Temperature(°C) | 500 | |||||
Lub oil Capacity(L) | 237.2 | |||||
Rated Fuel Consumption(L/h) | 376 | |||||
Alternator | Model | XN7H | ||||
Rated Power(kW/kVA) | 1600/2000 | |||||
Power Efficiency | 95.2% | |||||
Voltage Regulation | ±1.0 | |||||
Excitation Type | Brushless | |||||
Insulation Class | H | |||||
Overall Size(mm) | Length | 6800 | ||||
Width | 2780 | |||||
Height | 3500 | |||||
Gross Weight(kg) | 12000 |
2000kva powerful diesel generator open/silent/trailer engine made in UK Price for sale Control Panel :
Automatic control panel
a)Automatic alarm system:The unit has the acousto-optics alarm system and arrestor for any situation as the start defeat,the water is over temperature,the oil pulls down,over speed,over load and over current.
b)Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible and visual alarm lamps and buzzers
2)Starting system :starter is used to start engine
3)Short circuit protection :MCCB air switch
4)Cooling system :combined cooling water tank fitted to meet the requirment of radiation at ambient temperature 40
5)Filter system :Oil,fuel and air filter
6)Accessories:exhaust elbow,bellow ,muffler
Standard control panel
Standard Control Panel is the basic configuration for normal operation and usage. It is of some advantage such as easy to operate various function and well protection. Operative buttons such as Turn On, Per-heart. Starting, Stop (Emergency Stop) on the panel .while malfunction occurs, control panel will stop the generator and also alarm with light or buzz.
Our partner :
As a excellent factory of diesel generator and gas generator ,we became the OEM factory ,engine factory ,like CUMMIN ,YUCHAI ,Ricardo and so on .Brand alternator OEM facotoy XN.Not only this ,but also often take part in the conference,like Deepsea ,like Smartgen .CoMap, Deepsea and so on .
OUR CUSTORMERS AND PRODUCTS :
AFRICA 500KW NATURAL GAS GENERATOR
SOUTH AMERICA 500KW NATURAL GAS GENERATOR
Our company has import and export rights,which has extablished business relationship with 28 provines,municipalities andd autonomous regions,mainly export products to over 40 countries and regions in European ,Africa,South America ,Southeast Asia, West asia etc.We have build stable,lont -term friendly relation and cooperation with more than 20countries such as Asia,Africa, America and European .
