Big power electrical governor type UK Engine diesel generator 1500KW for sale Specification :
1.1MV diesel generator water cooled uk engine Sale with stamford, Leroy Somer, Marathon ,and China brand alternator .
2.We supply spare parts during the whole service life.
3.One year warranty or 1500hours .Ane we are manufacturer with 2 factories in weifang city ,after sale service guranteed.
4.Perkins ,Cummins engine 750kva with global warranty .
5.Open frame type /Silent type /weatherproof type /Trailer type /Container type at your option.
| Genset Model | Open Type | SP1500GF | ||||
| Silent Type | SP1500GFS | |||||
| Prime Power(kW/kVA) | 1500/1875 | |||||
| Standby Power(kW/kVA) | 1650/2062 | |||||
| Diesel Engine | Model | 4016TAG1A | ||||
| Type | water-cooled,inline, 4-stroke,direct injection ,wet cylinder liner | |||||
| Rated Power(kW) | 1537 | |||||
| Intake Type | Turbocharged | |||||
| No.of Cylinder | 16.V | |||||
| Bore x Stroke(mm) | 160x190 | |||||
| Compression Ratio | 13.6:1 | |||||
| Mechanical Governor Rate | 5% | |||||
| Electronic Governor Rate | 1% | |||||
| Noise Level (dBA) | 103 | |||||
| Exhaust Temperature(°C) | 500 | |||||
| Lub oil Capacity(L) | 237.2 | |||||
| Rated Fuel Consumption(L/h) | 353 | |||||
| Alternator | Model | XN7F | ||||
| Rated Power(kW/kVA) | 1500/1875 | |||||
| Power Efficiency | 95.2% | |||||
| Voltage Regulation | ±1.0 | |||||
| Excitation Type | Brushless | |||||
| Insulation Class | H | |||||
| Overall Size(mm) | Length | 6800 | ||||
| Width | 2780 | |||||
| Height | 3500 | |||||
| Gross Weight(kg) | 12000 | |||||
Big power electrical governor type UK Engine diesel generator 1500KW saleControl Panel :
a)Automatic alarm system:The unit has the acousto-optics alarm system and arrestor for any situation as the start defeat,the water is over temperature,the oil pulls down,over speed,over load and over current.
b)Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible and visual alarm lamps and buzzers
2)Starting system :starter is used to start engine
3)Short circuit protection :MCCB air switch
4)Cooling system :combined cooling water tank fitted to meet the requirment of radiation at ambient temperature 40
5)Filter system :Oil,fuel and air filter
6)Accessories:exhaust elbow,bellow ,muffler
