High Quality X-Ray Fluorescence Spectrometer for Precious Metals
Noble Metal Elements(such as Au, Ag, Pt, Rh, Ru, Ir, Pd, Cu, Zn, Ni, etc.) analysis is able to achieve by XRF Spectrometer.
During the producing and recycle process in the jewelry industy, there are some lost.
XRF Spectromete will help to save the lost part and inspect the alloy quality. The traditional testing method (such as fire assay and
chemical ways) are ruinous. And it takes along time to prepare for the samples.
XRF testing is nondestructive and we don’t need prepare for the sample. The whole testing process only takes couple of minutes.
All the liquid, soild and powder samples are available.
Measuring element comprehensive: the test substance most widely covers the precious metals industry all metals and mending,
capable of measuring: Gold(including K-gold)Platinum, Silver, palladium, Rhodium, Copper, Zinc, n Zn, Nickel, Tungsten etc,
around seventy-two kinds of metal elements, Outstanding performance of analysing complex alloy gold and platinum samples
which includes iridium, tungsten and other.
BENEFITS
1.High precision: +/- 0.1 under Optimized Test Conditions with Homogenous Sample.
2.Inbuilt PC &Touch screen interface reduce the space and cabling issues.
3.Measuring element comprehensive: the test substance most widely covers the precious metals industry all metals and mending,
capable of measuring: Gold(including K-gold) Platinum, Silver, palladium, Rhodium, Copper, Zinc, n Zn, Nickel, Tungsten etc,
around seventy-two kinds of metal elements, Outstanding performance of analysing complex alloy gold and platinum samples
which includes iridium, tungsten and other.
4.Wide range applications: for production and processing of gold and silver jewelry, gold and silver recovery and purification,
jewelry identification (pawn shops and swap lines),Hallmark and test lab monitoring.
FEATURES
Powders
Grinding(<400 mesh if possible) can minimise scatter affects due to particle size. Additionally, grinding insures that the
measurement is more representative of the entire sample, vs, the surface of the sample.
Pressing(hydraulically or manually )compacts more of the sample into the analysis area, and ensures uniform density and
better reproducibility.
Solids
Polishing surfaces will also minimise scatter affect.
Flat samples are optimal for quantitative results.
Liquids
Samples should be fresh when analysed and analysed with short analysis time-if sample is evaporative.
Sample should not contain precipitants/soilds
1.Easy Operation: Put the sample, open the software, select the template, click the Test button, then wait 30 to 50 seconds, You
can get accurate and intuitive test results.
2.This is an on-side laboratory, reliable, accurate, fast elemental analysis. This will provide a real competitve advangage.Thus you
will get huge gains, and promote your leadership in the industry.
3.The value of gold is displayed in percentage and Karat, simple and intuitive.
4.Gold and silver jewelry can be qualitive indentification within 3 seconds, 30 to 60 seconds automatically calculate the precise
content of jewelry.
Specification |
Parameter |
Working Priciple |
Energy Dispersive X-Ray Fluorescence |
Measurement&Weight |
450*660*285mm/33kg |
Detection limit |
100ppm |
Precison |
+10ppm~0.1% |
Expanded uncertainty |
≤0.19% |
Operating Environment |
Temperature≤70% Humidity -11~46℃ |
Hight Voltage |
0~55Kv/0~1mA |
Detector |
Si-Pin145Kev+5 |
Integrated Computer |
High-strength metal frame and industrial motherboard & multi-point hand touch |
Testable Competer |
Any 20 Elements from whole elements(Na-U) |
Active radiation protection |
√ |
High Voltage Protection |
√ |
X-Ray Tube overheating protection |
√ |
Extension wire and the auxiliary bracket |
√ |
Malfunction Analyse |
√ |
Buck-boost pre-boot |
√ |
Internal Printer |
√ |
Remote installation and training |
√ |
Lifelong fress up grades of software |
√ |
1. Our company is committed to provide products and service of the highest quality and greatest value to our customers.
2. We provide one-year free warranty and lifetime maintenance for our products by email.
3. If you have any technical questions, please feel free to contact us.
