Help CenterHeavy Duty Gantry Cnc Plasma Cutting Machine for Metal Cutting
Related Products
-
Light Duty Gantry Cnc Gas Cutting Machine for MetalUS$ 8,500 - 15,000MOQ: 1 Set -
Heavy Duty Gantry Cnc Plasma Cutting MachineUS$ 12,000 - 25,000MOQ: 1 Set
-
Heavy Duty Gantry Cnc Gas Cutting Machine Cnc Flame Cutting Machine for MetalUS$ 12,000 - 30,000MOQ: 1 Set
-
Table Cnc Flame Cutting MachineUS$ 12,000 - 25,000MOQ: 1 Set
-
Table Cnc Gas Cutting Machine for Metal CuttingUS$ 12,000 - 25,000MOQ: 1 Set
Gantry cnc cutting machine, gantry cnc cutter, cnc cut off machine, dragon cnc cutting machine, cnc plasma cutting machine, cnc plasma cutter, metal cutting machine, dragon cnc cutter
The main structure and features of gantry cnc plasma cutting machine
- The beam adopts enhanced wide body box structure and endframe adopts low center of gravity, make the equipment durable and symmetric. All the welding points are stress released to ensure the whole rigidity strength and dynamic balance.
- The machine is equipped with gear rack, servo motor and planetary reducer on both horizontal and vertical direction, the horizontal move adopts high precision drive rail and steel belt, can transmit stably on the same or specular direction between master-slave cutting torches.
- Crossbeam drive adopts PMI linear guide rail , to ensure the moving accuracy and cutting quality.
- Well performed Thermadyne, Hypertherm and Kjellberg plasma power supply optional
- Automatic memory function when power off or emergency stop.
- Auto alarm function when faced with a mistake or arc breaking.
- Multilanguage(English, Chinese, French, Germany, Portuguess, Spanish ect) switch on the interface.
- 17" LCD touch screen, convenient design, easy to operate.
The configuration and parameters of gantry cnc plasma cutting machine
| Configuration | |||||
| Structure | Wide body strengthen welding box structure | ||||
| Drive motor | Panasonic servo motor | ||||
| Reducer | Shimpo | ||||
| Crossbeam guide rail | PMI linear guide rail | ||||
| Guide rail | 43kg heavy guide rail | ||||
| CNC system | SJTU-SK (Hypertherm Micro EDGE, EDGE PRO optional) | ||||
| Nesting software | FASTCAM | ||||
| Automatic height controller | HYD arc voltage THC | ||||
| Plasma power supply | Thermadyne, Hypertherm and Kjellberg | ||||
| Specification | |||||
| Voltage | 220V | ||||
| Working temperature | - 10°C -45°C | ||||
| Humidity | <95%, no condensation | ||||
| Crossbeam width | ≥500mm | ||||
| Cutting thickness | 0.5 to 50mm | ||||
| Cutting speed | 50 to 8000 mm/min | ||||
| Travel speed | 1 to 12000 mm/min | ||||
| Cutting width | 0.8m less than track width | ||||
| Cutting length | 2m less than track length | ||||
| Torch lifting height | 200mm | ||||
| Cutting material | mild steel, stainless steel, aluminium etc | ||||
| Operation language | Multilanguage | ||||
Main parts of gantry cnc plasma cutting machine
1. SJTU-SK control system
2. High precision Panasonic servo motor
3. Automatic HYD THC(torch height control)
4. Hypertherm, Thermadyne, Kjellberg plasma power supply
5. 38kg leve heavy guide rail
6. Smooth linear guide rail on crossbeam
7. Intensive welding box structure
Our services
- 12 months warranty since machine reaches at buyer's place
- Any after sale questions will be replied within 24 hours
- Free installing and operating train
- Offer testing certification before delivering
- Installing and cutting video can be provided
- Engineers are available to service aboard
Zhangzhou Honghui Electrical Equipment Devolopment Co.,Ltd is a manufacture focus on producing CNC cutting machine and inverter welding machine for many years, the configuration of our machines are choosen by our technicists and engineers through over and over test and experiment, make sure it has better performance and higher quality on the cutting and welding job.
If any question or interest about our machines, kindly please contact us, we will give you a satisfied replay as soon as possible.
