Specifications
1)enviromental protection2)high-efficiency
3)quick drying
High speed polythene printing machine
Usage:
This flexible printing machine is suitable for printing such packing materials as roll paper,
plastic film bag, foil, non woven fabric etc. And it is a kind of ideal printing equipment for
producing paper packing bag food, supermarket handbag, vest bag and clothes bag etc.
Main Specifications and the Features:
1. Easy to operation, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity
3. Off –printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. Rewinding and unwinding system adopts tension controller, magnetic powder and
EPC device to achieve good print effect
5. The use of special helical-tooth gear, color matching is accurate
6. There are two sets of heating devices, including central heating and constant
temperature control system for drying system
7. Low-roller special steel processing, and special process, and plating thickness of 0.1mm
protective layer of hard chromium
9. With the cold wind system, can effectively prevent from ink adhesion after printing
10. The printing produces are clear and good arrangement quality
Type |
MT-4600 |
MT-4800 |
MT-41000 |
Max.Effective Printing Width |
560mm |
760mm |
960mm |
Max.Web Width |
600mm |
800mm |
1000mm |
Max.Printing Speed |
80m/min |
80m/min |
80m/min |
Max.Mechanical Speed |
90 m/min |
90 m/min |
90 m/min |
Max.Diameter of Roll Material |
450mm |
450mm |
450mm |
Internal Diameter of Roll Core |
76mm |
76mm |
76mm |
Rang of Repeat Printing Length |
191-1500mm |
191-1500mm |
191-1500mm |
Accuracy of Registration |
±0.3mm |
±0.3mm |
±0.3mm |
Plate Thickness(Bothside adhesive included) |
2.38mm |
2.38mm |
2.38mm |
Heating Power |
7Kw |
10.5Kw |
14Kw |
Total Power |
11.5Kw |
15Kw |
18.5Kw |
Weight of Machine |
3000kg |
3500kg |
4000kg |
Overall Dimension |
L4300×W1600×H2500mm |
L4300×W1800×H2500mm |
L4300×W2000×H2500mm |
.
