Specifications
1.used for paper,platic film2.non woven facbric,aluminium foil
3.efficient
One color press machine for aluminium
Usage:
This flexible printing machine is suitable for printing such packing materials as polyethylene, polypropylene bag, glass paper and roll paper etc. And it is a kind of ideal printing equipment for producing paper packing bag food, supermarket handbag, vest bag and clothes bag etc.
Performance and characteristic:
1,Easy operation, gentle starting, color printing accurate.
2,The meter counter can set printing quantity according to the requirements, stop the machine automatically at the quantity or when the material is cut off.
3,Air operated rise and fall printing plate drum, after fluctuation printing ink automatic agitation.
4,The net grain drum passes on the ink, the black color is even.
5,Reliable dry system, coordinate high-speed operation, engine off automatic abruption.
6,360 degrees continuously adjustable longitudinal to flowered installment.
7,Frequency conversion velocity modulation, adaptation different printing speed.
8,On the version roller seat and receives on material to be loaded with the spot to move and the pause button, is advantageous for when the justification operates the machine
Main Technical Variable:
Model |
MT-1600 |
MT-1800 |
MT-11000 |
Max. width of substrate |
600mm |
800mm |
1000mm |
Max. printing width |
560mm |
760mm |
960mm |
Range of Printing length |
191 to 1500mm |
191 to 1500mm |
191 to 1500mm |
Max. diameter of web |
450mm |
450mm |
450mm |
Printing speed |
50 to 80m/min |
50 to 80m/min |
50 to 80m/min |
Plate thickness |
2.38mm |
2.38mm |
2.38mm |
Total power |
3.9Kw |
4.5Kw |
5.8Kw |
Machine weight |
1300kg |
1500kg |
1700kg |
outline diameter |
1500*1600*1200mm |
1500*1800*1200mm |
1500*2000*1200mm |
