Multi color printing paper machine
Usage
Introduce sensitization resin as flexible printing plate, especially suitable for printing non woven fabric material, also can be print packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.
Main Specifications and The Features:
1. Easy to operation, accurate color, long life
2. The use of motors, variable frequency speed control, saving electricity
3. Off –printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink
4. Rewinding and unwinding system adopts tension controller, magnetic powder and EPC device to achieve good print effect
5. The use of special helical-tooth gear, color matching is accurate
6. There are two sets of heating devices, including central heating and constant temperature control system for drying system
7. Low-roller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium
8. Ceramic rollers with hard oxidation, treating by dynamic balance, static balance, can achieve perfect printing effect
9. With the cold wind system, can effectively prevent from ink adhesion after printing
10. The printing produces are clear and good arrangement quality
Model of Machine |
MT-6600 |
MT-6800 |
MT-61000 |
Max.Width of Printing Material |
600mm |
800mm |
1000mm |
Max.Printing With |
560mm |
760mm |
960mm |
Length Range of Printed Product |
191-914mm |
191-914mm |
191-914mm |
Max.Diameter of Roll Material |
φ450mm |
φ450mm |
φ450mm |
Printing Speed |
5∼50m/min |
5∼50m/min |
5∼50m/min |
Thickness of plate(Including Two-sides Glue Paper) |
2.38mm |
2.38mm |
2.38mm |
Total Power |
13kw |
15kw |
18kw |
Weight of Machine |
3500kg |
4200kg |
5000kg |
Overall Dimensions |
3900×1660×2950mm |
3900×1860×2950mm |
3900×2060×2950mm |
