Specifications
Composite Plate Production Line1.high quality
2.reasonable price
fessional standard
ing efficiently
Brand New Composite sandwich Plate Production Line
Brief introduction
Yingkou Longshun Machinery Manufacturing Co., Ltd. is an enterprise professionally engaged in research,design,construction and installation.Our company takes producing color steel forming equipment series as the central task.The main production contain arch sheet machine,composite sandwich plate machine,purlin machine,flat sheet machine,and guard rali forming machine.
Introduction
Sandwich panel production line is used to produce new building materials with stable, light,
solid features and goodlooking appearance. Using sandwich panel, it is convennient and fast
to construct large scale houses like supermarkets, workshops, warehouses.They also can be
used to construct freezing houses, purifying houses and air-conditioning houses, etc
Machine Output and features
Features of EPS press machine,EPS sandwich panel line
The EPS/ rock wool sandwich panel line can produce color steel sandwich panel with various specifications including EPS flat board, EPS matchboard, EPS corrugated sheet board,rock wool flat board, rock wool corrugated board,ect.
The panel line include machinery partelectrical control system part and additional machine for panel
Overall power equipment:35kw.
Size of the mineral wool sandwich panel line : overall length of the line is 34000mm,overall width of the line is 3100mm,overall height of the line is 2200mm,Overall weight of the line:22t
eps sandwich panel machine application: 2 types of panel: Wall panel and Roof panel.
2. Panel core material: EPS, Rock wool, PU, XPS, Glass wool and other insulation material
3. Steel coil width: 1000mm, 1200mm, 1250mm
4. Panel length: 1200mm, be adjustable
5. Panel thickness: 30 -- 300mm
6. Production speed: 0-5 meter/Min
7. Capacity: 450,000 -- 600,000M2 per year
8. Power supply: AC 380/50-60Hz
9. Install power: 28 -- 35 kw
10. Workshop area: 1,000M2
11. Control system: PLC control system
12. Layout:Uncoiler - Roll forming - Lamination(eps press machine) - sandwich panel cutting machine - Output table
13. We also can make the mineral wool sandwich panel line .welcome to inquiry our eps panel production line
Specification
Overall dimensions:48000mm*4500mm*2700mm
Operation voltage:380V
Total power consumption:32kw
Weight:21 tons
Working speed:0-4.5m/min
Material thickness:0.3-0.8mm
Core thickness:20-300mm
Core material:EPS,rock wool and glass wool
Control system: PLC with touchscreen,Convertor
Our service
Our products can be made according to your requirement.
Excellent quality and reasonable price to provide.
We do quotation within 24 hours and welcome your any inquiry at any time.
More detail pelease call or email to me directly,thank you !
My Skype ID : roll forming machine-plenet
My phone No.008618341774968
Payment Term and condition
* Payment Term: 30 T/T in advance, 70% T/T before delivery
* Delivery Time: Within 20 Days after receipt of the down payment
* Warranty: 1 year and life-long maintain
* Installation Days: about 5 days
* Transporting: 1x40ft container
