Ceramic Honeycomb Extruder
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, Wall tile making machine
Brick Raw Material:
Clay
Processing:
Brick Molding Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiangtan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Other, Wall tile making machine
Brick Raw Material
Clay
Processing
Brick Molding Machine
Method
Vacuum Extruder
Automatic
Yes
Place of Origin
Hunan, China
Brand Name
Weida
Model Number
WDY series
Power
5.5-11KW
Specifications
1Vertical extruding2 Ceramic honeycomb making
3 Hydraulic preuusre
WDYY series ceramic honeycomb extruder used plastic extruding technology, horizontal tilting installation, is a special equipment for vertical extruding honeycomb ceramic product. Equipped with vacuum pump enable extruding various kinds of ceramic honeycomb such as solid, hollow, fine hole shape. The machine is chracterized by high extruding pressure, easy to operation, widely application and steady performance.
| Model | WDYY80 | WDYY68 | WDYY40 | WDYY25 | |
| Main cylinder pressure | 800KN(80T) | 680KN(68T) | 400KN(48T) | 250KN(25T) | |
| Main cylinder stroke | 660mm | 500mm | 400mm | 350mm | |
| Dia of extruding screw | Φ250x550 | Φ200x500 | Φ250x500 | Φ250x350 | |
| Rotating speed of stirring shaft(up) | 16Mpa | 20Mpa | 20Mpa | 20Mpa | |
| Rotating speed of stirring shaft(down) | 5Mpa | 20Mpa | 5Mpa | 5Mpa | |
| Motor power | 11KW | 11KW | 7.5KW | 5.5KW | |
| Motor | 2XA-4A | ||||
| oil tank capacity | 200L | ||||
| feed barrel corner | 0-65°C | ||||
| Extruder adjustable angle | 0-90° | ||||
| Oil for hydraulic station | Antiwear oil 46° | ||||
| Main cylinder speed | return speed | ≤1.5m/min | |||
| stable extrusion speed | 0.1-0.7m/min | ||||
