Wall Tile Making Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Other, Wall tile making machine
Brick Raw Material:
Clay
Processing:
Brick Molding Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiangtan
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Other, Wall tile making machine
Brick Raw Material
Clay
Processing
Brick Molding Machine
Method
Vacuum Extruder
Automatic
Yes
Capacity
3-7T/H
Place of Origin
Hunan, China
Brand Name
Weida
Model Number
TCJ650
Power
112KW
Specifications
1terracotta facade making2water cooling system
3unqiue machine in China
4New curtain wall making
5 extrusion power>10Mpa
Model TCJ650 4-Shaft Vacuum Extruder is a patented product with latest technology, the maximum extrusion more than 130kg/cm3. We are the only one manufacure which be enquipped with the technology for making this machine in China
The machine is mainly used to produce large size exterior tile, external tile,outside tiles,curtain walls such as terracotta panel, it is also available for extruding other ceramic productions such as thin board,hollow board.
The machine is equipped with vacuum pump to removes the air from the clay, improve the plastic and elastic of clay. The R. P. M of mixing auger and extruding auger is driven by variable frequency variable speed motor respectively, the R. P. M is adjustable per your production's requirement.
| Data | Variable |
| Moisture of pug | 16-21% |
| Capacity | 3-7t/h |
| Rotate speed of stiring screw | ≥12.8 r/min(adustable) |
| Rotate speed of extruding screw | ≥19.8 r/min(adustable) |
| Diameter of extruding screw | φ320x2mm |
| Pressure of extudsion | ≥10MPa |
| air clutch working press | 0.5-0.8MPa |
| Vacuum degree | 98kpa |
| Motor power | 102kw |
| Overall size | About 5350×1677×2060mm |
| Net weight | 12000kg |
