4 Colour Flexo Printing Machine

4 Colour Flexo Printing Machine photo-1
US$ 23,500 - 32,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, Flexography
Place of Origin:
Zhejiang, China
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Other, Flexography
Place of Origin Zhejiang, China
Brand Name CHANGS
Model Number HSR-320
Usage Bill Printer, Paper Printer
Automatic Grade Automatic
Voltage 380V/50HZ
Gross Power 14KW
Dimensions(L*W*H) 2100*1100*2500 mm
Weight 1800KG
Certification ISO
After-sales Service Provided Engineers available to service machinery overseas

Feature:



1. Adopts ceramic mesh roller to convey ink.
2. Magnetic powder brake and slutch control the feeding and rollingor discharging.
3. Each printing unit adopts 360-degree registering adjuster.
4. Each printing unit is equipped with an assemble of auto infrared drying installation.
5. The inking roller can depart fromth emachine and rotate at low speed in order to keep the ink from drying when its stops.
6. The main motor adopts stepless governor converter.
7.It can finish in one time from feeding paper webs ,printing, printing in corotating-reverse manner, glazing, automatic infrared drying, laminating, cross cutting and rolling. It is an ideal machine for the printing factories to print high-grade self-adhesive trademarks.



Main technical parameter:

Model

HSR320-6B

HSR480-6B

Printing speed

50m/min

50m/min

Printing color

4colors

4colors

Max. Web width

330mm

480mm

Max. Printing width

320mm

460mm

Max. Unwinding diameter

600mm

600mm

Max. Rewinding diameter

550mm

550mm

Printing girth

180-420mm

180-420mm

Precision of registration

±0.10mm

±0.10mm

Dimensions

2100*1100*2500(mm)

2300*1200*2700(mm)

Machine weight

About 1800kg

About 1900kg
