YT series fully automatic bopp film flexo printer for film

Specifications

bopp film flexo printer
Max. Width of Printing Material 600mm 800mm 1000mm
Printing Speed 5~50m/min

bopp film flexo printer

Performance:

Introduce sensitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

Features:

1. Easy operation, flexible starting, accurate color register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6. 360°continuous and adjustable longitudinal register device.
7. The frequency control of motor speed adapts to different printing speeds.
8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
9. Magnetic powder brake for unwinding tension control, magnetic powder clutch for rewinding tension control.
10. With double unwinding &rewinding shaft.

Main Technical Variables:

Model of Machine	YT-4600	YT-4800	YT-41000
Max. Width of Printing Material	600mm	800mm	1000mm
Max. Printing With	560mm	760mm	960mm
Length Range of Printed Product	191-914mm	191-914mm	191-914mm
Max. Diameter of Roll Material	φ450mm	φ450mm	φ450mm
Printing Speed	5~0m/min	5~0m/min	5~0m/min
Thickness of plate(Including Two-sides Glue Paper)	2.38mm	2.38mm	2.38mm
Total Power	10.87kw	12.5kw	14.37kw
Weight of Machine	3000kg	3500kg	4000kg
Overall Dimensions	4200×1600×2400mm	4200×1800×2400mm	4200×2000×2400mm
