UV-9200 UV-Visible Spectrophotometer

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Shanghai Houstec Instrument Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

FEATURES:

1 Microprocessor control, 16×2 LCD display;

2 Auto zero and auto 100%T adjustment provided;

3 Calibration curve can be set up by either measuring or entering up to 10 standards or entering K and B factors directly via the

keyboard;

4 Parameters can be saved for later use; Up to 10 calibration curves can be stored and edited for user's convenience;

5 Standard manual 4-cell holder accommodates cells from 5-50mm and changeable to long path length cell holder of 100mm.

6 Data can be printed out via a printer port;

7 PC control measurement can be achieved via a USB port for more accurate and flexible requiements.

SPCIFICATIONS:

Model	VIS-7220G	UV-9200
Wavelength	320~1100nm	190~1100nm
Wavelength accuracy	±2.0nm
Wavelength reproducibility	1nm
Monochromator	Single-beam, C-T type, grating 1200L/mm
Photometric accuracy	±0.5%T
Photometric reproducibility	0.3%T
Stray light	0.1%T(NaNO2 at 340nm)	0.1%T (Nal at 220nm, NaNO2 at 340nm)
Spectral bandwidth	2nm (1, 4, 5nm optional)
0%T stability	0.2%T(30min)
100%T stability	0.001A/30min (at 500nm, after warming up)
Operation mode	T, A, C, E
Photometric range	-0.3~3A
Display	16X2 LCD
Detector	Silicon Photodiode
Light source	Tungsten halogen lamp	Tungsten halogen lamp, D2 lamp
Power Requirement	110V—240V, 50/60HZ
Power consumption	100W	120W
Dimensions	530×410×210mm
Net weight	15kg	16kg
