color steel rolling shutter door guide rail cold forming
machine professional manufacturer
Main specifications of steel best roller shuttering door making machine
Take one type of machine for example:
Processing material |
colored steel plate, galvanized plate, or aluminium plate |
| Material thickness | 0.8---1.2 mm |
| Material hardness | 550 mpa---350 mpa |
| Material width | 1000mm |
| Formed width | 747mm |
| Forming speed | 12m/min |
Working Process of this machine:
Decoiling--active feeding--roll forming--measuring length--pressing--cutting to length--product to stand
Main elements:
Decoiler, main forming machine, hydraulic pressing, hydraulic cutting, product stand, hydraulic system, electric system.
1. Decoiler
il inner diameter: 450-550mm
il max width: 1250mm
3.max carrying capacity: 5000kg
Usage:It is used to support the steel coil and uncoil it in a turnable way.
Passive uncoil pulled by roll forming system
2. Active feeding
Usage:Put the raw material(steel plate) through the beach to manufacture and process,
it can guarantee that the products are neat, parallel and everything is uniformity.
Please refer to the equipment regulation to know the function of locate angle iron.
3. Main forming machine of steel best roller shuttering door making machine
1. Shaft material & rollers material & shaft diameter
45# steel adjustable treatment; 45# steel, polished, plate of chrome 0.05mm; 60mm
2. power: 101kw
3. Transport; Motor; chain drive
4. Forming speed; 20m/min
Usage: In order to keep the product shape and precision, adopts welded sheet structure, motor
reducer drive, chain transmission,roller was chromed which can keep the molding plate surface
smooth and not easy to be marked when it is being stamped.
4. Hydraulic cutting of steel best roller shuttering door making machine
1). Material: blade, puncher and mold material: Cr12 steel with quenched treated 60-62
2).Cutting system: advanced hydraulic drive, automatic cutting after forming, no distorting or
wasting, high level safety factor.
It adopts the hydraulic drive and automatic location to decide the dimension and cut the target
products.
Material of blades: Cr12 quenched
Power supply : hydraulic power
Components:It contains one set of blade, one hydraulic tank and one cutter machine
5. Product stand
6. Hydraulic system
1. Advanced hydraulic system from Taiwan
2. Power: 5.5kw
7. Electric system
1. screen: text screen displayer
2. PLC: Taida DVP14ES from Taiwan
8. Products
Warranty
1). One year, and we will provide the technical support for the whole life.
2).Training: the buyer should charge of visa, return ticket, food and accommodation overseas and
USD50/person/day for salary.
3). Need one technicians
4).Training time: one week (contains the time of installation and adjustment)
compamy
