Self supporting GSM antenna telecommunication towers
Self supporting GSM antenna telecommunication towers have good rigidity, suitable for high requirements for horizontal displacement of base station; simple structure, easy processing, convenient for factory production. Generally high tower type, suitable for meet the requirements. Don't need to apply to large hoisting equipment, installation is convenient. Applicable to rural and suburban area which is open, lower area on the appearance requirements.
Product name | Self supporting GSM antenna telecommunication towers |
Application: | Telecommunication, Electric Power Transmission and Distribution |
Tower shape: | Triangular , Square, Polygonal or Conical |
Material : | Q345B/A572,minimum yield strength >=345N/mm2; |
Wind Pressure: | 0.35~0.45 KN/M2 |
Surface treatment: | Hot dip galvanization/paint as per ISO 1461 or ASTM A123 |
Connection method: | Bolts, Slip joint, flanged connected |
Life time: | 50 years |
Necessary Accessories: | Antenna cage; antenna mount pole; lighting rod; bracket for obstacle light; bolts & nuts |
Tower height: | 5-200M |
Welding: | CO2 welding or Submerged arc auto methods |
Working & Resting Platform Quantity: | 1-4PCS |
Antenna Support: | 6-30pcs |
Microwave Dish: | 6-30pcs |
Quality system: | GB/T19001-2008-ISO9001,GB/T 24001-2004-ISO 14001,GB/T28001-2001 |
Packing: Covered by Mat or straw bale at the top and bottom or other packages suritable for seaworthy.
Shipping: Within one month after contract signed.
First Tower Co., Ltd. located in the famous China's largest production base. Our company's fixed capital is more than 5000 million RMB, with more than 400 existing stuff nowadays, covering an area of more than 60 acres. Our company is a combination of design, production, transportation, installation and maintenance. The main products of our company are corrugated metal culverts, assembled corrugated culverts, iron tower,transmission line tower,four column pipe tower, television tower, wind tower, lightning tower, watchtower, Self supporting GSM antenna telecommunication towers etc.
Our products have passed ISO9001:2008 quality management system certification and always promote and implement ISO9001 standard. Our company has realized "informatization management"
- One-stop Service
- 20 year experience of manufacturering.
- Large Factory with Complete Facility
- Machine and Weather-ability Testing Machines, etc . .
- Advanced Technology
- Price Term: EXW, FOB, CFR or CIF.
- MOQ: 1 sets for Customized
- Payment: Typically 30% by T/T as deposit, balance by T/T or L/C at sight before shipment. Other payment way can be negotiated.
- Delivery time : goods can be ready for shipment within 10 workdays after receiving deposit.
- Warranty : 30 years
- Surface treatment :hot dip galvanization
