Help CenterUV-6100A Spectrophotometer
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
shanghai metash
Model Number:
UV-6100A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UV-6100S SpectrophotometerUS$ 6,000 - 8,000MOQ: 1 Piece -
UV-6000 Singles Beam UV Visible Spectrophotometer Analytical Lab InstrumentsNegotiableMOQ: 1 Piece
-
UV-6000PC SpectrophotometerNegotiableMOQ: 1 Piece
-
UV-5800 SpectrophotometerNegotiableMOQ: 1 Piece
-
UV-5600 SpectrophotometerNegotiableMOQ: 1 Piece
Place of Origin
Shanghai, China
Brand Name
shanghai metash
Model Number
UV-6100A
Size
625*430*206mm
Weight
31kg
Wavelength Range
190-1100nm
Measurement Range
0-200%T, -0.3-3.0A
Features
1, Variable Bandwidth
2, The precisely aligned detector and quality deuterium and halogen lamps enhance the precision across the UV/vis spectrum starting from 190nm and into the near-infrared 1100nm.
3, Online software upgrade capability via Internet(for stand-alone models)
4, Full A4 print-out of graphs and tables of results with popular inexpensive printers such as HP or Epson Deskjet.
5, Real-time clock for date and time stamping of results
6, Large LCD display (320*240 Dots Matrix)
Specifications
| Model | UV-6100A |
| Optical System | Single Beam(1200 Lines/mm Grating) |
| Wavelength Range | 190-1100nm |
| Bandwidth | 1nm |
| Wavelength Accuracy | ±0.3nm |
| Wavelength Repeatability | 0.2nm |
| Photometric Accuracy | ±0.3%T |
| Photometric Repeatability | 0.2%T |
| Photometric Range | -0.3-3A,0-200%T,0-9999C |
| Stability | ± 0.001A/h @ 500nm |
| Baseline Flatness | ± 0.001A/h |
| Noise | ± 0.001A/h |
| Stray Light | ≤0.05%T @ 220nm,360nm |
| Data Output Port | USB |
| Printer Port | Parallel Port |
| Display | 320*240 Dots LCD |
| Lamps | D2 Lamp & W Lamp |
| Detector | Silicon Photodiode |
| Power Requirements | AC 220V/50Hz or 110V/60Hz |
| Dimension | 625*430*206mm |
| Weight | 30kg |
