UTP Patch Panel 16 Port RJ 45 Cat5e Patch Panel

UTP Patch Panel 16 Port RJ 45 Cat5e Patch Panel

Features

Meets ANSI/TIA/EIA-568-B.2 Category 5e requirements

Meets TIA/EIA TSB-40

Meets ISO/IEC Generic Cabling Standard 11801

Description

Diminished size for mounting in 10" wall mount cabinets

This patch panel is designed for 22 – 26 AWG solid conductors

Height: 1U

Materials

Housing: ABS 94V-0                fiber patch panel

IDC: PC UL94V-0

PCB: FR-4 1.6 mm (0.06") thick, 2 layers

Contacts: 0.35 mm (0.014") phosphor bronze with 1.27 micron (50 microinches) gold plating on contact area

Metal housing: 1.6 mm (0.06") metal thick

Construction characterisic features

Color marking of conductors according to T568B and T568A

Numeral marking on the front side of the panel

Space for additional marking

Color and numeral marking of IDC modules on the rear side of the panel

Hyperline patch-cord usage provides the best connection

110 type punch down tool is used for cable termination

Electrical characteristics

According to UL 1863

Current rating: 1.5 A max

Voltage rating: 150 V

Contact resistance: 20 mOhm

Insulation resistance: 500 MOhm

Dielectric withstand voltage: 1000 V AC RMS, 60Hz/1min
