Soundproof Diesel Generating Set
US$ 1,999 - 3,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
kipor
Model Number:
diesel generating set
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
10 to 150kw Chinese Engine Diesel Generator With EPAUS$ 2,000 - 2,999MOQ: 1 Set -
10kw Diesel Generator Set,silent Diesel Generator 10kw/12kvaUS$ 2,000 - 2,100MOQ: 1 Set
-
10kw 10kva Silent Diesel GeneratorNegotiableMOQ: 1
-
20kw 25kva Diesel Silent Electric GeneratorNegotiableMOQ: 1
-
10 to 200KW China Engine Silent Diesel GeneratorUS$ 1,399 - 9,999MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
kipor
Model Number
diesel generating set
Output Type
AC Three Phase
Speed
1500rpm & 1800rpm
Frequency
50Hz & 60Hz
Rated Power
10-50Kva
Rated Voltage
230/400v, 120/208v
Rated Current
14.42-60.85A
Specifications
soundproof diesel generating set1.Rated power: 10-50Kva
2.Volt: 400/230v .120/208v
3.low oil
Supply 10-50Kva soundproof diesel generating set for sale
Engine: QUANCHAI.YANGDONG or LAIDONG
Alternator: Stamford tech Brushless alternator
Alternator features:
1) Brush-less, 4 poles, rotation magnet
2) IP21-23 (NEMA1) enclosure is standard for all industrial alternators
3) The insulation system is class H
4) Simple installation and maintenance, with easy access to terminals, rotating diodes and coupling bolts
5) Wide range of flange adaptors and single bearing disc coupling
6) Standard 2/3 pitch windings avoid excessive neutral currents
| Genset Type | DG-11 | DG-11 | DG-14 | DG-16 | DG-23 | DG-28 | DG-38 | |
| Prime Power(kwkva) | 8.811 | 8.811 | 10.814 | 12.816 | 1823 | 2528 | 3038 | |
| Stand Power(kwkva) | 912 | 912 | 1215 | 1518 | 2025 | 2831 | 3342 | |
|
Diesel Engine |
Brand | YANGDONG | ||||||
| model | YSAD380D | Y385D | YD480D | YND485D | YSD490D | Y4100DD | Y4102D | |
| prime power (kw) | 10 | 11 | 13 | 17 | 19 | 25 | 33 | |
| Diesel Engine Type | naturally aspirated, forced water cooling | |||||||
| cylinder no. | 3L | 3L | 4L | 4L | 4L | 4L | 4L | |
| Bor*stroke(mm) | 80*90 | 85*90 | 80*90 | 85*95 | 90*100 | 100*105 | 102*118 | |
| chamber type | direct injection | |||||||
| smooth speed ratio | ≤5% | |||||||
| Starting systerm | Electric Starting | |||||||
| Diesel-Consumption (g/kw.h) | <265 | <262 | <249 | <245 | <243 | <240 | <238 | |
| Brushless Alternator | Type | STG164B | STG164B | STG164C | STG164D | STG184E | STG184G | STG184H |
| Rated Power(Kva) | 8.811 | 8.811 | 10.814 | 12.816 | 1823 | 2528 | 3038 | |
| Characteristic | Class H IP 23 3phase 4pole with AVR | |||||||
| Bearing | single | single | single | single | single | single | single | |
| coupling | Direct | Direct | Direct | Direct | Direct | Direct | Direct | |
| voltage regulation | 0.50% | 0.50% | 0.50% | 0.50% | 0.50% | 0.50% | 0.50% | |
| Genset | Standar parts: |
storage batter. 8hours the fuel tank.Emergency stop switch.shock absorbers. radiator.silencer,drain outlet ,fuel systerm etc |
||||||
| Additional Part: | Digital Control Panel and Genset protection | |||||||
| Noise (db) | silent genset 55-78 dba @ 7m , open type75-98 dba @7m | |||||||
| Dim(mm |
1660x880 x950 |
1660x880 x950 |
1830x880 x950 |
1830x880
x950 |
2000x900 x1040 |
2000x900 x1040 |
2000x900 x1040 |
|
| New Weight(kg) | 600 | 650 | 750 | 800 | 900 | 950 | 950 | |
GENSET PHOTO
CERTIFICATE
WORK ROOM
PROTECTION CONTROLLER
