JY-G200 High Performance Emulsified Industrial Oil Purification Equipment for Factories With Polymer Membrane Technology
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Flow:
32L/min,40L/min,63L/min
Working Pressure:
0.2~0.35Mpa
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JY-T100 Deep Filtration Diesel Decontamination Equipment for Mechanical Processing With Long Service LifeNegotiableMOQ: 1 Set -
High Interception Rate Industrial Cleansing System for Mining With Oil-water Separation in South AmericaNegotiableMOQ: 1 Set
-
High Performance Diesel Cleansing Machine for Construction With Deep FiltrationNegotiableMOQ: 1 Set
-
Large Flow Industrial Filtration System for Mining With Polymer Membrane Filtration TechnologyNegotiableMOQ: 1 Set
-
Highly Cost-effective and Long Life Diesel Oil and Water Separate Filtes for Fishery Industrial With Two-level FiltrationNegotiableMOQ: 1 Set
Condition
New
Flow
32L/min,40L/min,63L/min
Working Pressure
0.2~0.35Mpa
Place of Origin
Liaoning, China
Brand Name
Jing Yuan
Model Number
JY-G200
Usage
Other, Industrial Oil
Voltage
380V
Certification
ISO9001:2008
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Excellent performance:
•New polymer membrane filtration technology
•Selectivity characteristics of polymer membrane is core technology.
•Oil-water separating is easy.
•High precision and deep filtration
•Guarantee the cleanness index of industrial oil
•Improve the efficiency of the engine
•Prolong engine service life
•The cost of filtration is low
| Technical Parameters | 1 | Model Number | JY-G200 |
| 2 | Working Pressure | 0.2~0.35Mpa | |
| 3 | Flow Rate | 32L/min,40L/min,63L/min | |
| 4 | Filtration Precision | 2,5,10,15,20,30μm | |
| 5 | Filtration Material | HDPE,PA | |
| 6 | Applicative Oil | Industrial Emulsified Oil | |
| 7 | Chemical Resistance | Widely Chemical Compatibility | |
| 8 | Power | 380V Motor | |
| 9 | Coalescence Filter Element | J150-500L | |
| 10 | Separation Filter Element | J150-500F | |
| 11 | Membrane Filter Element | J30-975H | |
| 12 | Service Life of Filter Element | 2~3 Year | |
| 13 | Warranty for Main Engine | 1 Year | |
| Functional Characteristics | 1 | Large flow diesel purification filter | |
| 2 | Polymer 3D mesh structure membrane filter element | ||
| 3 | High precision filtration | ||
| 4 | High interception rate | ||
| 5 | Oil-water separation | ||
| 6 | High dehydration efficiency | ||
| 7 | Combining precision filtration and high efficient dehydration | ||
| 8 | Continuous processing | ||
| 9 | Clean degree can reach NAS5 grade | ||
| 10 | Water rate in oil is less than 100ppm | ||
| 11 | Keeping the physical and chemical character of the oil | ||
| 12 | Extending oil service life | ||
| 13 | Low energy consumption, low operation cost | ||
| 14 | Simple and convenient operation and maintenance | ||
| 15 | Design life is more than 20 years (except for filter element) | ||
| Principle | Selectivity characteristic is to say, the oil molecules will pass and water molecules or impurities will be intercepted, so that the oil and water can be separated. | ||
| It adopts dehydration technology “coalescence separation”and coalescence separation filter targeted at oil special ratio on the basis of different medium surface tension to remove the emulsified water. | |||
| Application | Factories, mines, mechanical processing, engineering machinery,power plant and other industries in Asia, South America, Africa and Middle East. | ||
| Why do we filter diesel? | 90% of the failure problem of diesel engine is due to dirt and moisture in the diesel. After multiple storage and transportation, the purity of the product will decline. So filtering out the pollutants and water is necessary to restore the purity of the product. Clean diesel makes fuel consumption reduces 5-10%, oil-saving effect is obvious, the service life of diesel engines extend 2 ~3 times. | ||
Application in fishery industry and dock
