Large Flow Industrial Filtration System for Mining With Polymer Membrane Filtration Technology
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Flow:
60L/min
Working Pressure:
0.2~0.35Mpa
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Highly Cost-effective and Long Life Diesel Oil and Water Separate Filtes for Fishery Industrial With Two-level FiltrationNegotiableMOQ: 1 Set -
Advanced Membrane Technology Diesel Oil Refinery Machine With SGS/ISO CertificationNegotiableMOQ: 1 Set
-
High-performance Diesel Filter Machine for Military Industry in IragNegotiableMOQ: 1 Set
-
High Interception Rate Aviation Kerosene Expert Filter With Deep FiltrationNegotiableMOQ: 1 Set
-
High-performance Diesel Filter for Mining Industry With Polymer Membrane TechnologyNegotiableMOQ: 1 Set
Condition
New
Flow
60L/min
Working Pressure
0.2~0.35Mpa
Place of Origin
Liaoning, China
Brand Name
Jing Yuan
Model Number
JY-G100
Usage
Insulation Oil
Certification
ISO9001:2008
After-sales Service Provided
Engineers available to service machinery overseas
Excellent performance:
•New polymer membrane filtration technology
•Selectivity characteristics of polymer membrane is core technology.
•Oil-water separating is easy.
•High precision and deep filtration
•Guarantee the cleanness index of industrial oil
•Improve the efficiency of the engine
•Prolong engine service life
•The cost of filtration is low
| Technical Parameters | 1 | Model Number | JY-G100 |
| 2 | Working Pressure | 0.2~0.35Mpa | |
| 3 | Flow Rate | 60L/min | |
| 4 | Filtration Precision | 2,5,10,15,25μm | |
| 5 | Filtration Material | HDPE,PA | |
| 6 | Applicative Oil | High viscosity industrial gear oil | |
| 7 | Chemical Resistance | Wide Chemical Compatibility | |
| 8 | Type of Filter element | J30-970S | |
| 9 | Power | 380V Electrical Engine | |
| 10 | Dimension | 800×750×1350mm | |
| 11 | Weight | 113KG | |
| 12 | Service Life of Filter Element | 2~3 Year | |
| 13 | Warranty for Main Engine | 1 Year | |
| Functional Characteristics | 1 | Large flow diesel purification filter | |
| 2 | Polymer 3D mesh structure membrane filter element | ||
| 3 | High precision two-level filtration | ||
| 4 | High interception rate | ||
| 5 | Oil-water separation | ||
| 6 | Potable trolley structure | ||
| 7 | Providing rapid fuel filtration service on site | ||
| 8 | Circulating filtration for oil storage tank | ||
| 9 | Made of high quality thick steel plate, anti-corrosion treatment | ||
| 10 | Minimum mechanical flow resistance | ||
| 11 | Low pressure difference | ||
| 12 | Motor gear pump group | ||
| 13 | Pumping the oil stored in tank into systematic oil tank | ||
| 14 | Purifying the oil under use | ||
| 15 | Design life is more than 20 years (except for filter element) | ||
| Principle | Selectivity characteristic is to say, the oil molecules will pass and water molecules or impurities will be intercepted, so that the oil and water can be separated. | ||
| Application | Factories, mines, mechanical processing, engineering machinery, wind generating electricity and other industries in Asia, South America, Africa and Middle East. | ||
| Why do we filter diesel? | 90% of the failure problem of diesel engine is due to dirt and moisture in the diesel. After multiple storage and transportation, the purity of the product will decline. So filtering out the pollutants and water is necessary to restore the purity of the product. Clean diesel makes fuel consumption reduces 5-10%, oil-saving effect is obvious, the service life of diesel engines extend 2 ~3 times. | ||
Application in military industry and fishery industry
