W Shape SiC Heating Element for Electric Furnace

FOB Price

US$ 20 - 500 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China		Brand Name	JK
Model Number	BN-S6

W shape SiC heating element for electric furnace

1.The advantage of the SiC heating element

a.The Max. surface temperature can reach 1500C

b.High infrared imessivity ,5-10 times higher than general nickel chrome wire .

c.High anti-bending strength ,as high as 100-120 MPa

d.High resistence to oxidation and corrosion .

e.Long service life ,easy to install and repair

2.W Shape SiC Heating Elements with the terminals at one end, are designed for three-phase power source applications, such as the float glass process

3.When you place an order of the W Shape SiC Heating Elements, please give following information:

OD:Outer Diameter;

HZ:Length Of Hot Zone;

CZ:Length Of Cold Zone;

OL:Total Length, A: Shank Spacing

4.Order Sample of the W Shape SiC Heating Element

W Shape: OD=20mm, HZ=250mm, CZ=350mm, OL=625mm, A=52mm,

Resistance: 0.9Ω Specify As: 20/250/625/52/0.9Ω
