Small hammer mill
Features:
1. It is of various types.
2. It is suitable for crushing maximum, medium and minimum stones.
3. It is easy to be operated.
4. Simple structure; High reduction ratio; Low operation cost; Easy maintenance;
Working Principle:
The motor drives the rotor rotates of the small hammer mill at a high speed through the belt, and on the rotor there are series hammers. When the materials get into the working area of hammers, they are crushed by the rotating hammers of the small hammer mill with high rotation speed, the products which are crushed to meet the required size can be discharged by the outlet and become the final products, the large size products are brought back to the crushed area by the hammers of the hammer mill for being re-crushed until they reached the required size.
Technical Parameters:
Type |
Rotor Diameter/Length mm |
Rotor Speed r/min |
Feed Size mm |
Max. Input Size |
Output Size mm |
Capacity |
Power |
Weight |
Size |
PC-41 |
φ400/175 |
1000 |
145×270 |
50 |
3 |
0.5 |
5.5 |
0.5 |
812×1056×1315 |
PC-44 |
φ400/400 |
1500 |
145×450 |
100 |
10 |
5~8 |
7.5 |
0.9 |
744×942×878 |
PC-64 |
φ600/400 |
1000 |
295×450 |
100 |
15 |
10~12 |
18.5 |
1.03 |
1054×972×1117 |
PC-66 |
φ600/600 |
1000 |
295×570 |
100 |
10 |
12~18 |
45 |
2.14 |
1315×840×1501 |
PC-86 |
φ800/600 |
1000 |
350×570 |
200 |
10 |
20-25 |
55 |
2.45 |
1515×2586×1040 |
PC-88 |
φ800/800 |
1000 |
350×850 |
200 |
15 |
35-45 |
55 |
3.05 |
1515×2831×1040 |
PC-108 |
φ1000/800 |
1000 |
580×850 |
200 |
13 |
25-40 |
110 |
6.5 |
3206×2210×1515 |
PC-1010 |
φ1000/1000 |
1000 |
580×1060 |
200 |
15 |
40-60 |
132 |
7.59 |
3514×2230×1516 |
PC-1010 |
φ1000/1000 |
1000 |
580×1060 |
200 |
10 |
30-50 |
160 |
7.59 |
3514×2230×1518 |
PC-1010 |
φ1000/1000 |
1000 |
580×1060 |
200 |
8 |
25-35 |
185 |
7.59 |
3514×2230×1518 |
PC-1212 |
φ1250/1250 |
750 |
650×1330 |
200 |
20 |
90-110 |
185 |
19.1 |
4475×3162×2250 |
PC-1414 |
φ1400/1400 |
750 |
1050×1540 |
250 |
20 |
120-170 |
280 |
17.2 |
2790×2800×2310 |
|
|
|
|
|
|
|
|
|
|
