Home > Manufacturing & Processing Machinery > Mining Machinery > Mining Mill > Ceramic Mill (86-15978436639)

Ceramic Mill (86-15978436639)

US$ 2,000 - 89,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Ball Mill

Capacity(t/h):

Min: 1.8t/h Max:34.5t/h

Contact Supplier Request Quote Chat Now

Gongyi Hengchang Metallurgical Building Material Equipments Plant

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Ball Mill

Capacity(t/h) Min: 1.8t/h Max:34.5t/h

Place of Origin Henan, China

Brand Name HC

Model Number YMQG series

Ceramic mill

Ceramic mill introduction:

Ceramic mill is an efficient tool for grinding many materials into fine powder. Ceramic mill is used to grind many kinds of mine and other materials, or to select the mine. Ceramic mill is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry process and the wet process.

Ceramic mill application:

The Ceramic mill is a key equipment for regrinding. Ceramic mill is widely used for the cement, the silicate product, new type building material, fire-proof material, chemical fertilizer, black and non-ferrous metal, glass, ceramics and etc. Our ceramic mill can grind ore or other materials that can be grinded either by wet process or by dry process.

Ceramic mill working principle:

This ceramic mill is horizontal type and tubular running device, has two warehouses. Ceramic mill is grid type and its outside runs along gear. The material enters spirally and evenly the first warehouse of the milling machine along the input material hollow axis by input material device. In this warehouse , there is a ladder scaleboard or ripple scaleboard, and different specification steel balls are installed on the scaleboard, when the barrel body rotates and then produces centrifugal force ,at this time , the steel ball is carried tosome height and falls to make the material grinding and striking.

Ceramic mill technical parameter:

Model	Barrel		Speed	Capacity	Feed size	Output size	Output	Motor		weight
Model	Dia.	Length	Speed	Capacity	Feed size	Output size	Output	Type	Power	weight
YMQG900×1800	900	1800	38	1.8	0-25	0.075-0.6	0.44-2.4	Y180L-6	15	4.2
YMQG900×3000	900	3000	38	2.5	0-25	0.075-0.6	0.7-2.9	Y180L-6	18.5	5.4
YMQG1200×2400	1200	2400	37	4.8	0-25	0.075-0.6	0.4-5.8	Y225M-6	30	8.2
YMQG1200×4500	1200	4500	37	5.2	0-25	0.075-0.6	1.4-5	Y280M-6	55	11
YMQG1500×3000	1500	3000	29	10	0-25	0.075-0.4	2.8-9	Y315S-6	75	16.3
YMQG1500×5700	1500	5700	29	12	0-25	0.075-0.4	3.1-7	Y315M-6	90	20.7
YMQG1830×6400	1830	6400	23.9	18.5	0-25	0.075-0.4	6-8.5	JR138-8	210	35.1
YMQG1830×7000	1830	7000	23.9	21	0-25	0.075-0.4	6-7	JR138-8	245	38
YMQG2200×6500	2200	6500	21.4	31	0-25	0.075-0.4	14-15	JR158-8	380	50
YMQG2200×7000	2200	7000	21.4	34.5	0-25	0.075-0.4	14-15	JR158-8	380	67.6
