2015 Coal rotary dryer with ISO9001 and CE certificate:
It is widely used in building materials, metallurgy, chemicals, coal, fertilizer industries to dry the materials with certain humidity or guanularity. The rotary dryer can be used for the drying of many rotary kiln dryer for sale materials,such as the coal slurry, the metal powder the building industry. and many other industry. Generally speaking it can dry the material from 30-40% humidity to 1-5% humidity. According to the different characteristic of the material, the model of the rotary dryer it use will be a little bit different.
1) About the material: what type of material will you dry?
2) About the capacity: How many material will dry per hour?
3) About the humidity: what is you initial moisture and what is the final mositure you required?
4) About the size: what is the size of your material?
The wet materials are conveyed to the hopper through the belt conveyor or bucket elevator, and then enter into the feed end through the hopper charger and the feeding pipe in sequence. The inclination of the feeding pipe must be greater than the natural inclination of materials in order to make the materials flow into the dryer smoothly. The dryer cylinder with slight inclination with the horizontal line. The materials enter from the higher end, and the heat carrier enters from the lower ender; the two contact each other from opposite directions, but there are also circumstances that the heat carrier flows into the dryer body together with the material.
Model (mm) |
Speed(r/min) |
Slope(%) |
Inlet Air Temperature(°C) |
Power(kw) |
Capacity(t/h) |
Weight(t) |
Φ800×8000 |
3-8 |
3-5 |
≤700 |
4 |
0.8-2 |
3.5 |
Φ1000×10000 |
3-8 |
3-5 |
≤700 |
5.5 |
1-3 |
5.6 |
Φ1200×10000 |
3-8 |
3-5 |
≤700 |
7.5 |
2-3.5 |
13.5 |
Φ1200×12000 |
3-8 |
3-5 |
≤700 |
11 |
2.5-4 |
14.2 |
Φ1500×12000 |
2-6 |
3-5 |
≤800 |
11 |
4-6 |
18.5 |
Φ1500×15000 |
2-6 |
3-5 |
≤800 |
18.5 |
5-8 |
21 |
Φ1800×18000 |
2-6 |
3-5 |
≤800 |
18.5 |
6-12 |
31 |
Φ2000×18000 |
1.5-6 |
3-5 |
≤800 |
22 |
8-15 |
35 |
Φ2200×12000 |
1.5-6 |
3-5 |
≤800 |
22 |
13-15 |
31.6 |
Φ2200×14000 |
1.5-6 |
3-5 |
≤800 |
22 |
14-16 |
33.5 |
Φ2200×16000 |
1.5-6 |
3-5 |
≤800 |
30 |
14-18 |
36 |
Φ2400×18000 |
1.5-6 |
3-5 |
≤800 |
45 |
16-22 |
42.8 |
Φ2400×20000 |
1.5-6 |
3-5 |
≤800 |
45 |
18-25 |
52 |
Φ3000×20000 |
1.5-6 |
3-5 |
≤800 |
55 |
25-30 |
77.8 |
Φ3000×25000 |
1.5-6 |
3-5 |
≤800 |
55 |
28-34 |
87.5 |
Packing:
1. Load into container
2. Spare parts will be pack into wooden case or bags
Shipping:
1. Sea or train delivery
2. Spare parts can be delivered by air
Vice Governor of Benue State, Nigeria (front)
Customer from Russia
Customer from Ethiopia
Clients from Sudan
Welcom to our factory for visiting, please contact:
