Specifications
1) Best value zirconia sintering electric furnace.2)CE &ISO 9001 approved .
3) 1 year warranty.
4) PID controlled
factory direct sell zirconia sintering electric furnace,save your cost!
The product is by our company independent research and development of powerful heating equipment, mainly used in denture zirconia sintering processing industry, can also be used in powder metallurgy industry under the high temperature materials in protective atmosphere of sintering and annealing.This product uses the import silicon molybdenum rods, heating furnace for the loading of automatic lifting structure, modelling is novel, scientific and reasonable structure, is a mainstream in the field of high temperature sintering equipment.
1, automatic lifting structure under loading type, in favor of taking and puting the sample.
2, unique atmosphere protection mode, make the atmosphere more scientific, high efficiency, energy saving;
3, double furnace shell structure, between the double hull adopts air cooling technology, can effectively reduce the temperature of the furnace shell;
4, the structure of the circular furnace, heating element type is circular distribution, uniformity of furnace temperature field;
5, adopt the wai lok fast connection, push type connection, fast operation, convenient;
6, stove adopts touch screen control system, the operation is fast, simple;Through our software, and computer networking, can realize single or many sets of electric remote control, real-time tracking, historical records, the output statements, and other functions;
7, to set over temperature alarming and power, leakage protection, safe and reliable operation.
Model |
SJQL-1700 |
Control way |
Touch screen smart control adjustment |
Chamber material |
Japanese technology of vacuum adsorption molding quality high purity polycrystalline alumina fiber curing furnace, heat preservation performance is good |
Heating element |
Mosi2 |
Thermocouple |
B |
Chamber size |
120×100mm |
Crucible size |
2floors dia100×35mm |
Max Temp. |
1600℃ |
Accuracy |
±1℃ |
Heating rate |
≤10℃/min |
Voltage |
AC220V |
Frequency |
50/60Hz |
Power |
2500W |
size |
660× 400× 950mm |
Weight |
70kg |
