Laboratory Heating Furnace Tilting Rotary Furnace
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
SIOMM
Model Number:
SHZL-1100
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Battery Materials Sintering Furnace Rotary FurnaceNegotiableMOQ: 1 Set -
SZGL-1200C High Temperature Tube Furnaces for SaleNegotiableMOQ: 1 Set
-
SZGL-1200C Both a Horizontal and Vertical Position Laboratory Tube Furnace 1200CNegotiableMOQ: 1 Set
-
SGL-1700 Single Zone and 3 Zone Horizontal Tube FurnacesNegotiableMOQ: 1 Set
-
SGL-1700 Horizontal Tube Furnaces With Single or Multiple Heating Zones With Independent Zone ControlNegotiableMOQ: 1 Set
Brand Name
SIOMM
Model Number
SHZL-1100
Place of Origin
Shanghai, China
Specifications
1) Best value tilting crucible furnace2)excellent Temperature Uniformity and Energy Efficiency for processing powder .
Chinese manufacturer supplier 1100C tilting crucible furnace ,factory direct price, save your cost.
Product Description
1100°C High Temperature Tilting Rotary Furnaces provide excellent Temperature Uniformity and Energy Efficiency for processing powder and granular materials. This high performance and long lasting Rotary Furnace is ideal for lab and small scale production application. It offers the best Value/Cost ratio for your investment. These furnaces are designed for Accurate Temperature, Rotation Speed, excellent Temperature Uniformity, Long Lasting Performance, and Safe Operation. Rotation Speed can be adjusted either manually or sync with Furnace Temperature by automation.
Detailed Images
Functions
- Moved 360°, rate of rotation can be adjusted. Built-in block
- pieces help flour specimen sinter.
- Mute material to rotate the furnace
- Alloy piper or quartz piper
- Visible 7 inch touch screen to control automatically
- Reserve vacuum, gas connector
- Approved by CE certification and ISO9001
- Used to sinter battery,flour ,particle.
Specification
Model |
SHZL-1100/SHZL-1200 |
| Constant temp.zone length | Φ100*280 |
| Diameter | Endings:Φ60*460mm Middle:Φ100*280mm, Total:1200mm |
| Heating element |
Swedish Kanthal |
| Thermocouple | American OMEGA |
| Control temp. | PID, 30 programs |
| Temperature | 1100 serial(alloy piper):≤1000℃,1200serial (quartz piper):≤1200℃ |
| Fine heating rate | ≤10℃/min |
| Accessories |
Sealed flanges 1 pcs, O rings 4 pcs, quartz tube 1 pcs, vacuum pump 1 set, pipe plug 4 pcs, oven gloves, crucible tongs each 1 pcs |
| Operation | By touch screen to control, Rate of rotation is 0-15RPM, angle:0-25° |
