SZGL-1200C both a horizontal and vertical position Laboratory Tube Furnace 1200C

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 300 Set / Sets per Month
Port Shanghai

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SIOMM		Model Number	SZGL-1200C
Place of Origin	Shanghai, China

Product Description

Specifications

1) Best value both a horizontal and vertical position Laboratory Tube Furnace 1200 deg.C
2)Single/more/lengthen heating zone

SZGL-1200C both a horizontal and vertical position Laboratory Tube Furnace 1200°C

Product Description

SZGL-1200C Multi-position vacuum tube furnace adopted imported polycrystalline alumina fiber curing furnace chamber with good insulation properties. And equipped with resistance wire as heating elements, intelligent program temperature control system, phase-shift trigger and SCR control. It can working at vertical or horizontal status can meet different experimental requirement. And it can working in vacuum or atmosphere, so used more widely.

Functions

1. Adopted KF quick flange sealing, only need a clamp flange the connection can be done. It is very convenient to put and take the specimen. Avoiding bolt leakage by artificial operation and reduced the ratio of heating tube damaging which caused by installation flanges;

2. The furnace tube can be working at any angle, vertical, horizontal or any else angle. Used more widely;

3. Adopt imported polycrystalline fiber vacuum absorption furnace chamber; the resistance wire is used high quality resistance alloy silk 0Cr27Al7Mo2, servicing time more longer;

4. Reserved vacuum, gas road fast interface, could working with our vacuum system or mixed gas system;

5. Reserved 485 convert interface, can be connected with PC through software. It has remote control, real time tracking, history recorder, and output report function. And can be installed the paperless recorder for data storage and output;

6. Built - in thermocouple, real-time monitoring the temperature of the heated material;

7. Over-temperature alarm and power failure, leakage protection, safe and reliable operation.

Product Uses

Used for universities, research institutions, industrial and mining enterprises to do high temperature sintering

atmosphere, atmosphere restoring, CVD/CVI experimental and vacuum annealing.

Specification

Model	SZGL-1200C(Approved by CE certificate, ensure the safety operation of the machine. Certificate No.: GB/1067/4189/12 Issue 1)
Furnace Chamber	Imported high pure polycrystalline alumina fiber from Japan, excellent heat preservation
Furnace tube size	Φ40/60600mm,Φ80/100700mm
Heating elements	Doped molybdenum resistance wire
Thermometric component	N-mode thermocouple
Temperature control mode	The temperature control system adopted artificial intelligence technology, PID regulation, self-tuning capabilities, 30 section temperature control program
Seal mode	Stainless steel the KF quick flange extrusion seal
Standard vacuum degree	≤50Pa (If need more high vacuum degree, can purchase different vacuum system)
Working temperature	≤1150℃
Max temperature	1200℃
Constant temperature accuracy	±1℃
Heating zone length	350mm
Max. Temperature rising rate	≤30℃/min
Recommend temperature rising rate	≤10℃/min
Rated power	2.5KW
Working power	AC220V 50HZ/60HZ
Weight	About 25kg
Standard accessories	Sealed flanges 1 pcs, O rings 4 pcs, quartz tube 1 pcs, vacuum pump 1 set, pipe plug 4 pcs, oven gloves, crucible tongs each 1 pcs
Optional purchase accessories	Furnace hobs; Mixed gas system; Low, medium and high vacuum system; All kinds of alumina crucibles; Alumina tube or quartz tube; Computer control software; Paperless recorder, etc.
