Home > Products > Package Machine > Vertical Type Hydraulic Four Sides Sealed Powder Packing Machine
Vertical Type Hydraulic Four Sides Sealed Powder Packing Machine
- Qingdao Shanghai Tianjin
- T/T L/C D/P D/A Credit Card
You May Like
-
Direct Factory Automatic Four Side Sealing Granule Packing Machine
-
Professional Vertical Hydraulic Automatic Carton Packer
-
Easier Use Automatic Hydraulic Vertical Mini Waste Paper Baling Machine
-
Factory Supply Recycling Baling Machine
-
Woven Bag Waste Carton Baling Compactor Machine
-
Plastic Compactor/baling Machine for Woven Bag
Product Details
| Condition | New | Application | Textiles, Other, Textiles, Plastic waste | |
| Packaging Type | Film | Packaging Material | Paper, Plastic, Other, Paper, Plastic, CLOTH | |
| Automatic Grade | Automatic | Driven Type | Hydraulic | |
| Voltage | 380V | Power | 2.2KW | |
| Place of Origin | Henan, China | Brand Name | OWEEI | |
| Model Number | Y-20 | Weight | 1500kg | |
| Dimension(L*W*H) | 1200*750*650mm | Certification | ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Applications of four sides sealed powder packing machine:
This series baler is widely used to press and pack jumbo bags, normal woven bags, and cloth, etc.
The four corners equipped with a limit pulley, it can reduce press plate skewing when working.
Features of four sides sealed powder packing machine:
Hydraulic system: through the manual valve, the cylinder piston drives the press plate up and down, and complete the compression- reset whole process;
Equipped with automatic over pressure overflow device, to ensure the machine work normally and safely under the specified pressure.
This series of balers, are of reasonable structure, convenient operation, strong packing, low noise, low power consumption and high efficiency.
Based on user’s requirements, we can install the automatically pushing device to reduce labor intensity, and ensure more convenient operation.
Technical details of four sides sealed powder packing machine:
Model | Y-20 | Y-30 | Y-40 |
Bale size (W×L×H) (mm) | 1200×750×650
| 1200×800×650 | 1200×850×700 |
Power (kw) | 2.2 | 3 | 4 |
Pressure (Mpa) | 6-8 | 8-12 | 8-15 |
Travel distance (mm) | 800 | 800 | 900 |
Control type | Manual | Manual | Manual |
Oil cylinder diameter (mm) | ¢125 | ¢125 | ¢140 |
Dimension(m) | 1.6×0.85×2.25 | 1.6×0.85×2.25 | 1.6×0.9×2.8 |
Weight (KG) | 1500 | 1600 | 1800 |
Now Contact Yilia to get best price immediately via Skype: yilia_9 or mobile: 0086 15890080350.
