Uses and Features:
ZDP Series double- disc refiner adopts mechanical seal, It is a ideal continuous beating equipment ,
has a compact construct, small footprint, high efficiency, low power consumption, adaptability,
simple operation, flexible adjustment and easy maintenance , a reliable seal to prevent leakage.
Technical parameters:
Model | ZDP380 | ZDP450 | ZDP550 | ZDP600 |
The diameterofthegrinding piece(mm) | 380 | 450 | 550 | 600 |
Production capacity (t/d) | 6-20 | 8-40 | 25-80 | 40-120 |
Into the pulpconcentration (%) | 2-5 | 2-5 | 2-5 | 2-5 |
Into the pulppressure (Mpa) | 0.1-0.3 | 0.1-0.3 | 0.1-0.3 | 0.1-0.3 |
With motor(kw) | 37-55 | 75-110 | 132-160 | 160-250 |
Weight(kg) | 1250 | 2000 |
|
|
Dimensions(mm)LWH | 2150×700×750 | 2855×1360×830 |
|
|
Item | Type | |
ZYPM-380 | ZYPM-450 | |
Disc Diameter mm | 380 | 450 |
Production capacity t/d | 6~20 | 8~40 |
Into the pulp concentration % | 2~5 | 2~5 |
Into the pulp pressure MPa | 0.1~0.3 | 0.1~0.3 |
A pulppipediameter mm | 80 | 100 |
With motor KW | Y250M-6/37-55 | Y315M-6/90 |
Equipment weight kg | 1250 | 2000 |
dimensions (L × W × H mm | 2050×615×650 | 2855×1360×830 |
We are the MANUFACTURER of high quality machines with competitive price! Such as toilet/tissue paper machine, cultural paper machine, newspaper machine, craft/kraft paper machine, corrugated paper machine, etc.
