Uses and Features:
ZDP Series double- disc refiner adopts mechanical seal, It is a ideal continuous beating equipment ,
has a compact construct, small footprint, high efficiency, low power consumption, adaptability,
simple operation, flexible adjustment and easy maintenance , a reliable seal to prevent leakage.
Technical parameters:
Model |
ZDP380 |
ZDP450 |
ZDP550 |
ZDP600 |
|
The diameterofthegrinding piece(mm) |
380 |
450 |
550 |
600 |
|
Production capacity (t/d) |
6-20 |
8-40 |
25-80 |
40-120 |
|
Into the pulpconcentration (%) |
2-5 |
2-5 |
2-5 |
2-5 |
|
Into the pulppressure (Mpa) |
0.1-0.3 |
0.1-0.3 |
0.1-0.3 |
0.1-0.3 |
With motor(kw) |
37-55 |
75-110 |
132-160 |
160-250 |
Weight(kg) |
1250 |
2000 |
|
|
Dimensions(mm)LWH |
2150×700×750 |
2855×1360×830 |
|
|
Item |
Type |
|
ZYPM-380 |
ZYPM-450 |
|
Disc Diameter mm |
380 |
450 |
Production capacity t/d |
6~20 |
8~40 |
Into the pulp concentration % |
2~5 |
2~5 |
Into the pulp pressure MPa |
0.1~0.3 |
0.1~0.3 |
A pulppipediameter mm |
80 |
100 |
With motor KW |
Y250M-6/37-55 |
Y315M-6/90 |
Equipment weight kg |
1250 |
2000 |
dimensions (L × W × H mm |
2050×615×650 |
2855×1360×830 |
