1092mm double-dryer can and double-cylinder mould paper making Machine
Ⅰ.Technical parameters:
1. Raw material: wood pulp ;
2 output paper style: A4 paper;
3. Capacity: 4T/D;
4. Output paper weight: 80-140g/m2;
paper width: 1200mm;
6. Width of copper cylinder: 1450mm
7. Rail gauge:1800mm;
8. Drive way: AC inverter speed,section drive;
Ⅱ.main structure and characteristic of main part:
1. Cylinder section: 1250mm×1450mm stainless steel cylinder mould 2(pcs), 400mm×1450mm
couch roll 3(pcs),reverse roll 1 (pcs), coated by rubber,rubber hardness HSD 38°C±2.
section: 450mm×1450mm marble roll 1 pcs, 400mm×1450mm rubber roll 1 pcs, ccoated
by rubber,rubber hardness HSD 90°C±2.pneumatic loading device.
3. Dryer section: 1500mm×1450mm alloy dryer can 2 pcs, 400mm×1450mm touch roll 1pcs,coated
by rubber,Rubber hardness HSD 90°C±2,pneumatic loading device.
4.Drive and control section: AC inverter speed,section drive;
Ⅲ.All Equipments:
NO. |
Item |
qty(set) |
1 |
paper making Machine |
1 |
2 |
double layer dryer can Exhausted hood |
1 |
3 |
axial-flow ventilator |
1 |
4 |
Roots vacuum pump |
1 |
5 |
Suction box |
2 |
6 |
1092mm winding machine |
1 |
7 |
1092mm calendar(3 rolls) |
1 |
8 |
1092mmrewind machine |
1 |
9 |
5m3 High consistency hydrapulper |
1 |
10 |
1.8m2 High frequency vibration screen |
1 |
11 |
380mm double disc Refiner |
1 |
12 |
sand remover(6 set) |
1group |
12 |
35m3 bleacher |
1 |
13 |
700mm Thruster |
4 |
14 |
CX0.9 centrifugal screen |
1 |
15 |
4 inch pulp pump |
3 |
16 |
6 inch pulp pump |
3 |
17 |
air pump cabinet |
1 |
18 |
inverter control cabinet |
1 |
19 |
work table |
1 |
20 |
2ton boiler(burn coal) |
1 |
...
