1092mm double-dryer can and double-cylinder mould paper making Machine
Ⅰ.Technical parameters:
1. Raw material: wood pulp ;
2 output paper style: A4 paper;
3. Capacity: 4T/D;
4. Output paper weight: 80-140g/m2;
paper width: 1200mm;
6. Width of copper cylinder: 1450mm
7. Rail gauge:1800mm;
8. Drive way: AC inverter speed,section drive;
Ⅱ.main structure and characteristic of main part:
1. Cylinder section: 1250mm×1450mm stainless steel cylinder mould 2(pcs), 400mm×1450mm
couch roll 3(pcs),reverse roll 1 (pcs), coated by rubber,rubber hardness HSD 38°C±2.
section: 450mm×1450mm marble roll 1 pcs, 400mm×1450mm rubber roll 1 pcs, ccoated
by rubber,rubber hardness HSD 90°C±2.pneumatic loading device.
3. Dryer section: 1500mm×1450mm alloy dryer can 2 pcs, 400mm×1450mm touch roll 1pcs,coated
by rubber,Rubber hardness HSD 90°C±2,pneumatic loading device.
4.Drive and control section: AC inverter speed,section drive;
Ⅲ.All Equipments:
NO. | Item | qty(set) |
1 | paper making Machine | 1 |
2 | double layer dryer can Exhausted hood | 1 |
3 | axial-flow ventilator | 1 |
4 | Roots vacuum pump | 1 |
5 | Suction box | 2 |
6 | 1092mm winding machine | 1 |
7 | 1092mm calendar(3 rolls) | 1 |
8 | 1092mmrewind machine | 1 |
9 | 5m3 High consistency hydrapulper | 1 |
10 | 1.8m2 High frequency vibration screen | 1 |
11 | 380mm double disc Refiner | 1 |
12 | sand remover(6 set) | 1group |
12 | 35m3 bleacher | 1 |
13 | 700mm Thruster | 4 |
14 | CX0.9 centrifugal screen | 1 |
15 | 4 inch pulp pump | 3 |
16 | 6 inch pulp pump | 3 |
17 | air pump cabinet | 1 |
18 | inverter control cabinet | 1 |
19 | work table | 1 |
20 | 2ton boiler(burn coal) | 1 |
...
