Specifications
overhead Crane
1.max capacity:20 t
2.Span:7.5-28.5m
3.Lifting height:6-24m
4.ISO/CE Professional Design
Explosion Proof overhead Crane for coal mining 48t
Single girder LB bridge crane is one of the overhead crane families.Characterized as compact structure, easy to operation and low maintenance, this kind of crane is widely used in plant, warehouse and workshop for material lifting and moving.
Specification:
1. Capacity range: 1-30ton.
2. Span length: 7.5-28.5m
3. Lifting height: 6-24m
4. Electric hoist: CD/MD Model.
5. Motors: cone squirre-cage
6. Power supply:380V/50Hz or as per client's requirement.
Safety feature:
1. Limit switch.
2. Overload stop device for hoisting.
3. Long bearing buffer for crane traveling.
4. Power failure backup.
Single Girder hoist type overhead travelling crane can be divided structurally into three parts as following:
1. Hoisting mechanism: Electric hoist with trolley traveling along the main bridge beam.
2. Crane traveling mechanism: Two end carriages with wheels driven by electric motor.
3. Steel structure: Main bridge beam and two end carriages.
Detailed features of explosion proof overhead crane 48t:
LB (LBD) type explosion-proof electric singlegirder crane is based on the LD type crane, designed and manufactured according to GB3836.1-2000 (explosive environment used explosion-proof electric equipment) and GB3836.2-2000 (explosive environment used electrical equipment, flameproof electrical equipment "d"). This crane has the characteristics of reasonable structure, strong rigidity, beautiful shape, strong explosion-proof ability. The whole machine supports the use with the HB (BCD) HBS (BMD) type explosion-proof electric hoist. This is a kind of light small hoisting machinery. The products are widely used in the factory, warehouse, and other different occasions to lift goods, and are suitable in inflammable, explosive environment. The Work environment temperature within - 25 °C ~ 40 °C.
Four major parts, the bridge, the electric hoist, crane traveling mechanism, and electric equipment.
36 V safe voltage protections.
The whole crane and electric hoist are equipped with safety device, such as the lifting limited switch, the destination travel limit switch.
Operation of the electric hoist and the Crane system adopts the conductive slide or the cable as the electric power transmission device.
Technical Data of explosion proof bridge crane :
Lifting Capacity(t) |
1~48T |
|||
Span(m) |
7.5~28.5 |
|||
Crane traveling mechanism |
Traveling speed(m/min) |
20 |
||
Speed ratio |
58.95 |
|||
Motor |
Type |
Cone squirrel-cage |
||
Power(kw) |
0.8*21.5*2/2.2*2 |
|||
Rotational speed(r/min) |
1380 |
|||
Lifting mechanism(Electric hoist)&Traveling mechanism |
Mode of electric hoist |
HB/BCD/BMD |
||
Lifting speed(m/min) |
8/0.8,7/0.7,3.5/0.35 |
8/7/3.5 |
||
Lifting height(m) |
6/9/12/18/24 |
|||
Traveling speed(m/min) |
20 |
|||
Motor |
|
Cone squirrel-cage |
||
Working system |
380v,50hz, three phase |
|||
Electric current |
Φ270,Φ400 |
|||
Wheel diameter |
37~70 |
|||
|
|
|||
Explosion proof grade |
ExdⅡBT4,ExdⅡCT4 |
|||
|
Henan Kuangshan Crane Co.,ltd was established on 1988, and now with more than 20 years it is a large-scale enterprise group with integrated business of crane on research, development, design, production, sale and installation with after-sale service. The company has formed a strong and comprehensive innovative system with complete set of advanced equipments and large-scale production ability in the fields of mechanic procession, thermal treatment, soldering, assembly, test, measuring, packing and delivery. With a strong sincerity, we would like to cooperate with many other friends from all other countries and establish a long-term business relation.
|
Overhead crane Gantry crane Electric hoist European style overhead Crane European style Electric Hoist |
HNKS CRANE CO.,LTD. ZD BRANCH
Mobile: 0086 138 371 93903
What's up: 0086 152 3716 2337
SKYPE: info.cranes-lucy
Add: Changyuan Henan China
For more information and details, including design of the crane, safety
features of each kind of crane, application of the machine, technical
parameters of the crane, production process, after-sale service, main part of the crane, package for the crane, loading pictures of cranes and all other information about our product, please kindly contact with Ms. Lukina. Ms. Lukina would give you a support as much as possible.
....
